Bently Nevada 330104-03-06-10-02-00 3300 XL 8 mm Proximity Probes In stock

Bently Nevada 330104-03-06-10-02-00 3300 XL 8 mm Proximity Probes In stock

Product Name:3300 XL 8 mm Proximity Probes

Brand Name:Bently Nevada

Model Number:330104-03-06-10-02-00

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330104 03 06 10 02 00 3300 xl 8 mm proximity probes in stock-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330104-03-06-10-02-00
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model Number	330104-03-06-10-02-00
Product Type	3300 XL 8 mm Proximity Probe
Thread Type	M10 × 1 Metric Thread
Armor Option	With Armor
Total Length	1.0 meter (3.3 ft)
Connector Type	Miniature coaxial ClickLoc connector
Linear Range	2 mm (80 mils)
Output Sensitivity	7.87 V/mm (200 mV/mil)
Frequency Response	0 to 10 kHz
Probe Tip Material	Polyphenylene Sulfide (PPS)
Probe Case Material	AISI 303/304 Stainless Steel
Cable Type	75 Ω Triaxial Cable
Operating Temperature	-52°C to +177°C
Connector Material	Gold-plated brass/beryllium copper
Recommended Gap Setting	-9 Vdc (1.27 mm / 50 mils)
Dimension	1.8x1.5x113cm
Weight	0.12kg
Compliance	API 670, CE, ATEX, IECEx, RoHS

Description

Bently Nevada 330104-03-06-10-02-00 is a high-performance eddy current proximity probe designed for continuous vibration and shaft position monitoring in critical rotating machinery. As part of the 3300 XL 8 mm Proximity Transducer System, this model delivers stable signal output, excellent linearity, and strong immunity to EMI/RFI interference in demanding industrial environments.

The 330104-03-06-10-02-00 probe features an armored cable construction with M10 × 1 metric thread design, making it suitable for turbines, compressors, pumps, and high-speed motor applications where mechanical durability and measurement accuracy are essential. Compared with earlier 3300 series probes, the 330104 series provides improved connector reliability, enhanced environmental sealing, and simplified field installation.

Compatible with 3300 XL Proximitor Sensors, extension cables, and non-XL 3300 series components, the 330104-03-06-10-02-00 proximity probe is widely used across power generation, oil & gas, petrochemical, and heavy manufacturing industries for predictive maintenance and machine protection systems compliant with API 670 standards.

Applications

Power plants: Used for turbine shaft vibration monitoring, generator protection, and rotational speed measurement.
Substations: Supports rotating equipment condition monitoring and auxiliary machinery diagnostics.
Chemical plants: Integrates with process compressors, pumps, and hazardous-area monitoring systems.
Steel mills: Performs reliable vibration measurement in high-temperature and high-EMI industrial environments.
Machinery manufacturing plants: Applied in automated production equipment, test benches, and precision rotating systems.
Oil & gas facilities: Provides continuous machine protection for compressors, turbines, and pipeline equipment.
Marine industry: Supports vibration monitoring for propulsion and auxiliary rotating machinery systems.

Features

Advanced 3300 XL eddy current sensing technology
API 670 compliant measurement performance
High resistance to EMI and radio-frequency interference
Armored cable construction for enhanced mechanical protection
ClickLoc connectors for secure and fast installation
Compatible with legacy 3300 series system components
Stable operation in harsh industrial environments
Excellent vibration and shaft position monitoring accuracy

Functions

Measures shaft vibration and displacement
Monitors rotor position in rotating machinery
Supports overspeed and Keyphasor reference applications
Provides continuous machine condition monitoring
Enables predictive maintenance and fault diagnostics
Delivers stable analog output for protection systems

FAQ

Q1: What is the main function of the 330104-03-06-10-02-00 probe?
A1: It is designed for non-contact vibration and shaft position monitoring in rotating machinery applications.

Q2: Is the 330104-03-06-10-02-00 compatible with older 3300 systems?
A2: Yes, it is backward compatible with many non-XL 3300 series 5 mm and 8 mm components.

Q3: Can this proximity probe be used in hazardous areas?
A3: Yes, the probe supports ATEX, IECEx, and CSA hazardous-area approvals when properly installed.

Q4: What industries commonly use this probe?
A4: Power generation, oil & gas, petrochemical, marine, and heavy manufacturing industries widely use this model.

Q5: Does the probe support high-temperature environments?
A5: Yes, standard versions operate up to +177°C, and extended-temperature options are also available.

Spares

Number	Describe
141078	3300 XL 8 mm and 3300 5 mm Proximity Transducer System manual for installation, operation, and maintenance reference
175751	Multi-purpose stainless steel housing, 12”×12”×6”, supports up to 8 DIN-mount or 6 panel-mount Proximitor Sensors with hazardous area certification options
176467	Compact stainless steel housing, 12”×8”×6”, supports up to 4 3300 XL Proximitor Sensors in DIN-mount or panel-mount configurations
330181	Stainless steel hazardous-area housing, 13”×9.5”×7”, designed for up to 8 DIN-mount or 6 panel-mount Proximitor Sensors
02120015	Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, custom length available
138492-01	Replacement panel-mount mounting pad for 3300 XL Proximitor Sensor installation
138493-01	Replacement DIN-mount mounting pad for DIN rail Proximitor Sensor mounting applications
148722-01	3300 XL test plug with color-coded banana plug leads for Proximitor Sensor signal testing and diagnostics
04310310	Panel-mount screw for 3300 XL Proximitor Sensor installation, 6-32 UNC thread forming type
03200006	Silicone self-fusing protective tape roll for connector insulation and environmental sealing protection
