Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330104-06-12-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330104-06-12-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification |
|
Model Number |
330104-06-12-10-02-00 |
|
Product Type |
3300 XL 8 mm Proximity Probe |
|
Thread Type |
M10 × 1 Metric Thread |
|
Armor Type |
Stainless Steel Armored Cable |
|
Total Cable Length |
1.0 meter (3.3 ft) |
|
Connector Type |
Miniature ClickLoc Coaxial Connector |
|
Cable Type |
Standard Cable |
|
Linear Range |
2 mm (80 mils) |
|
Sensitivity |
7.87 V/mm (200 mV/mil) |
|
Frequency Response |
0 to 10 kHz |
|
Probe Tip Material |
Polyphenylene Sulfide (PPS) |
|
Probe Case Material |
AISI 303/304 Stainless Steel |
|
Operating Temperature |
-52°C to +177°C |
|
Recommended Gap Setting |
-9 Vdc at 1.27 mm |
|
Minimum Shaft Diameter |
50.8 mm (2 in) |
|
Dimension |
1.8x1.5x123cm |
|
Weight |
0.14kg |
|
Certifications |
CSA, ATEX, IECEx compatible platform |
|
Mounting Compatibility |
DIN rail and panel-mounted systems |
330104-06-12-10-02-00 is a high-performance eddy current proximity probe from the Bently Nevada 3300 XL series, engineered for continuous shaft vibration and position monitoring in rotating machinery. This model features an armored 8 mm probe with M10 × 1 metric thread construction, delivering reliable signal stability in demanding industrial environments such as turbines, compressors, pumps, and high-speed motors.
Compared with conventional proximity sensing solutions, 330104, 330103, and other 3300 XL 8 mm Proximity Transducer System models provide improved mechanical durability, enhanced EMI/RFI resistance, and superior interchangeability between probes, extension cables, and Proximitor sensors. The integrated ClickLoc connector system simplifies installation while maintaining secure long-term connections under vibration-intensive operating conditions.
Designed to comply with API 670 requirements, 330104-06-12-10-02-00 supports precise dynamic vibration and axial position measurements across power generation, petrochemical, and heavy industrial applications. Its stainless-steel armored cable structure and rugged probe body help extend service life in high-temperature and oil-exposed environments while reducing maintenance downtime and calibration complexity.
Q1: What is the main use of the 330104-06-12-10-02-00 probe?
A1: It is primarily used for shaft vibration and position monitoring in rotating industrial machinery.
Q2: Does the 330104 model include armored cable protection?
A2: Yes, this version features stainless-steel armored cable construction for enhanced durability.
Q3: Is the probe compatible with API 670 monitoring systems?
A3: Yes, the 3300 XL 8 mm system is designed to meet API 670 performance requirements.
Q4: What connector type does this probe use?
A4: It uses a miniature coaxial ClickLoc connector for secure and tool-free installation.
Q5: Can the probe operate in hazardous industrial environments?
A5: Yes, the platform supports CSA, ATEX, and IECEx certified installation configurations.
| Number | Describe |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System manual for installation, operation, and maintenance reference |
| 175751 | Multi-purpose stainless steel housing, 12”×12”×6”, supports up to 8 DIN-mount or 6 panel-mount Proximitor Sensors with hazardous area certification options |
| 176467 | Compact stainless steel housing, 12”×8”×6”, supports up to 4 3300 XL Proximitor Sensors in DIN-mount or panel-mount configurations |
| 330181 | Stainless steel hazardous-area housing, 13”×9.5”×7”, designed for up to 8 DIN-mount or 6 panel-mount Proximitor Sensors |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, custom length available |
| 138492-01 | Replacement panel-mount mounting pad for 3300 XL Proximitor Sensor installation |
| 138493-01 | Replacement DIN-mount mounting pad for DIN rail Proximitor Sensor mounting applications |
| 148722-01 | 3300 XL test plug with color-coded banana plug leads for Proximitor Sensor signal testing and diagnostics |
| 04310310 | Panel-mount screw for 3300 XL Proximitor Sensor installation, 6-32 UNC thread forming type |
| 03200006 | Silicone self-fusing protective tape roll for connector insulation and environmental sealing protection |
