Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330104-12-20-10-01-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330104-12-20-10-01-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Description |
|
Model Number |
330104-12-20-10-01-00 |
|
Product Series |
3300 XL 8 mm Proximity Probe |
|
Probe Type |
Eddy Current Proximity Probe |
|
Thread Type |
M10 × 1 |
|
Cable Protection |
Armored Cable |
|
Total Length |
1.0 meter |
|
Connector Type |
Miniature coaxial ClickLoc connector |
|
Output Sensitivity |
200 mV/mil (7.87 V/mm) |
|
Linear Range |
2 mm (80 mils) |
|
Operating Temperature |
-52°C to +177°C |
|
Probe Material |
Stainless Steel |
|
Frequency Response |
0 to 10 kHz |
|
Dimension |
111x2x1.6cm |
|
Weight |
0.16kg |
Bently Nevada 330104-12-20-10-01-00 belongs to the 3300 XL 8 mm Proximity Transducer System, designed for accurate shaft vibration and position monitoring in critical rotating machinery. The probe features an M10 × 1 threaded stainless-steel housing with armored cable construction, providing excellent durability in demanding industrial environments such as turbines, compressors, and generators.
Built for high-performance machinery protection applications, 330104-12-20-10-01-00 delivers stable eddy-current sensing technology with outstanding linearity, temperature stability, and electromagnetic interference resistance. The probe works together with 3300 XL extension cables and 3300 XL Proximitor Sensors to provide reliable dynamic vibration and axial displacement measurements for API 670 compliant monitoring systems.
Compared with traditional proximity probes, the 330104, 330103, and other 3300 XL series sensors offer improved connector reliability, enhanced environmental sealing, and simplified installation. The ClickLoc connector design and rugged armored cable structure help reduce maintenance requirements while improving long-term operational reliability in harsh industrial conditions.
Power Plants: Used for steam turbine vibration monitoring and generator protection systems.
Substations: Supports auxiliary equipment monitoring and predictive maintenance applications.
Chemical Plants: Integrates with compressors, pumps, and process automation systems.
Steel Mills: Provides reliable machinery monitoring in high-temperature industrial environments.
Machinery Manufacturing Plants: Applied in automated production lines and spindle monitoring systems.
Oil & Gas Facilities: Used for compressor monitoring and turbine protection applications.
Marine & Offshore Platforms: Supports rotating machinery condition monitoring in offshore systems.
Q1: What is the main application of the 330104-12-20-10-01-00 probe?
A1: It is mainly used for shaft vibration and position monitoring in rotating machinery.
Q2: Is the 330104-12-20-10-01-00 compatible with API 670 systems?
A2: Yes, the 3300 XL series is designed to meet API 670 requirements.
Q3: Does this probe support harsh industrial environments?
A3: Yes, the armored cable and stainless-steel construction provide excellent durability.
Q4: What connector type does the probe use?
A4: It uses a miniature coaxial ClickLoc connector for secure installation.
Q5: Can the probe be used in turbine monitoring systems?
A5: Yes, it is widely used in steam turbines, compressors, and generator monitoring applications.
| Number | Describe |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | Multi-purpose stainless steel housing, 12”×12”×6”, supports up to 8 DIN-mount or 6 panel-mount Proximitor Sensors, ATEX Zone 0/1 certified |
| 176467 | Multi-purpose stainless steel housing, 12”×8”×6”, supports up to 4 Proximitor Sensors in DIN or panel-mount configurations |
| 330181 | Stainless steel hazardous-area housing, 13”×9.5”×7”, supports up to 8 DIN-mount or 6 panel-mount Proximitor Sensors |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire |
| 138492-01 | Replacement panel-mount mounting pad for 3300 XL Proximitor Sensor |
| 138493-01 | Replacement DIN-mount mounting pad for 3300 XL Proximitor Sensor |
| 148722-01 | 3300 XL test plug for Proximitor Sensor performance verification without removing field wiring |
| 04310310 | Panel-mount screw for 3300 XL Proximitor Sensor installation |
| 03200006 | Silicone self-fusing tape for connector insulation and environmental protection |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables |
| 136536-01 | Connector protector adapter for pre-1998 installation tools with 75Ω ClickLoc connectors |
| 40180-02 | Package of connector protectors for 3300 XL 8 mm probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for extension cable environmental protection |
