Product Name:3300 XL 8 mm Reverse Mount Probes
Brand Name:Bently Nevada
Model Number:330105-02-12-15-12-CN
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330105-02-12-15-12-CN |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Details |
|
Model |
330105-02-12-15-12-CN |
|
Product Type |
3300 XL 8 mm Reverse Mount Probe |
|
System |
3300 XL Proximity Transducer System |
|
Thread Type |
3/8-24 UNF |
|
Probe Diameter |
8 mm |
|
Total Length |
1.5 m (configurable option) |
|
Cable Type |
75Ω triaxial (FEP insulated) |
|
Connector Type |
ClickLoc coaxial connector |
|
Measurement Range |
0.25 – 2.3 mm linear range |
|
Operating Temperature |
-52°C to +177°C |
|
Dimension |
163x1.2x1cm |
|
Weight |
0.06kg |
|
Mounting Type |
Reverse mount design |
The 330105-02-12-15-12-CN is a Bently Nevada 3300 XL 8 mm reverse mount proximity probe engineered for high-precision vibration and position monitoring in rotating machinery. It is widely applied in turbine systems, compressors, and critical industrial equipment where stable and accurate displacement data is essential.
As part of the 3300 XL Proximity Transducer System, the 330105-02-12-15-12-CN works seamlessly with extension cables and Proximitor sensors to deliver reliable eddy current measurement signals. It supports both static and dynamic shaft monitoring, making it suitable for predictive maintenance and condition-based diagnostics.
Designed with robust industrial-grade construction and ClickLoc connector technology, this reverse mount probe ensures strong mechanical stability, easy installation, and long service life. It complies with API 670 requirements and supports interchangeable system components for flexible industrial integration.
Power Plants: Used for turbine vibration monitoring, generator shaft displacement detection, and protection systems.
Substations: Enables signal acquisition, relay protection, and electrical equipment condition monitoring.
Chemical Plants: Supports process automation, hazardous area monitoring, and equipment safety control.
Steel Mills: Used in high-temperature machinery vibration tracking and electromagnetic interference environments.
Machinery Manufacturing: Applied in production lines, robotics systems, and rotating equipment diagnostics.
Q1: What is the 330105-02-12-15-12-CN used for?
A1: It is used for vibration and shaft position monitoring in industrial rotating machinery.
Q2: Is this probe compatible with the 3300 XL system?
A2: Yes, it is fully compatible with the Bently Nevada 3300 XL Proximity Transducer System.
Q3: What type of installation does it support?
A3: It uses a reverse mount design for secure and stable industrial installation.
Q4: Can it operate in harsh environments?
A4: Yes, it is designed for high temperature, vibration, and EMI-prone environments.
Q5: Does it support interchangeable components?
A5: Yes, it is fully interchangeable with other 3300 XL probes, cables, and sensors.
| Number | Description |
|---|---|
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread forming mounting screw. Four screws required per Proximitor sensor; supplied with 3300 XL panel-mount housings. |
| 03200006 | Silicone self-fusing tape, 9.1-meter roll designed for connector protection, providing electrical insulation and environmental sealing; not recommended for internal machine casing use. |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools for field assembly. |
| 136536-01 | Connector protector adapter enabling compatibility with pre-1998 installation tools for 75Ω ClickLoc connector systems. |
| 40180-02 | Connector protectors package containing 10 pairs for 3300 XL 8 mm probes and extension cables, providing environmental sealing protection. |
| 03839410 | 75Ω triaxial male connector protector designed for installation on extension cables and mating with female protectors on probes for environmental protection. |
| 03839420 | 75Ω triaxial female connector protector installed on probe lead or extension cable to protect Proximitor sensor connections from environmental exposure. |
| 04301007 | 3/8-24 probe lock nut with safety wire holes, single unit with dual drilled holes for secure mechanical locking using safety wire. |
| 04301008 | M10 x 1 probe lock nut with safety wire holes, designed for secure probe mounting with safety wire locking mechanism. |
| 330153-01 | 3300 XL connector kit for 8 mm probes and extension cables, including male/female ClickLoc connectors, color-coded sleeves, slit FEP tubing, and silicone tape. |
| 330153-09 | 3300 XL ETR connector kit for high-temperature applications, includes ClickLoc connectors, high-temperature FEP tubing, sleeves, and silicone tape. |
| 163356 | Connector Crimp Tool Kit including multi-connector inserts and installation instructions, compatible with 330153 connector kits and ClickLoc systems (post-2003). |
