Product Name:3300 XL 8 mm Reverse Mount Probes
Brand Name:Bently Nevada
Model Number:330106-05-30-50-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330106-05-30-50-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Details |
|
Model |
330106-05-30-50-02-00 |
|
Series |
Bently Nevada 3300 XL 8 mm |
|
Type |
Reverse Mount Proximity Probe |
|
Total Length |
5.0 m system cable |
|
Connector Type |
Miniature ClickLoc coaxial |
|
Cable Type |
Standard / FluidLoc optional |
|
Thread Type |
M10 x 1 |
|
Material |
Stainless steel probe body |
|
Operating Temp |
-52°C to +177°C |
|
Storage Temp |
-52°C to +260°C |
|
Output Type |
Eddy current analog signal |
|
Measurement Range |
0.25–2.3 mm linear range |
|
Dimension |
20x20x2cm |
|
Weight |
0.2kg |
The 330106-05-30-50-02-00 proximity probe is part of the advanced Bently Nevada 3300 XL 8 mm transducer family, engineered for precise vibration and position monitoring in rotating machinery. As part of the 3300 XL 8 mm / 330106 series, it delivers stable signal output for critical industrial asset protection and predictive maintenance systems.
The 330106-05-30-50-02-00 is designed for high reliability in harsh environments, offering excellent resistance to EMI/RFI interference and ensuring consistent measurement accuracy. It is fully compatible with 3300 XL extension cables and Proximitor sensors for flexible system integration.
Widely used with 330140 / 330141 probes and 3300 XL systems, it supports turbine monitoring, compressor protection, and high-speed rotating equipment diagnostics with long-term operational stability.
Q1: What is the 330106-05-30-50-02-00 used for?
A1: It is used for vibration and position monitoring in rotating industrial machinery.
Q2: Is the 330106-05-30-50-02-00 compatible with 3300 XL systems?
A2: Yes, it is fully compatible with Bently Nevada 3300 XL Proximitor systems.
Q3: Can this probe be used in high-temperature environments?
A3: Yes, it supports up to +177°C operating conditions.
Q4: Does it support FluidLoc cable protection?
A4: Yes, FluidLoc cable option is available for oil-resistant applications.
Q5: What industries commonly use this model?
A5: Power generation, petrochemical, steel plants, and machinery manufacturing.
| Number | I/O Module (Coated) |
|---|---|
| 148722-01 | 3300 XL test plug for Proximitor sensor performance testing via terminal test pins |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC mounting hardware |
| 03200006 | Silicone self-fusing tape roll for connector insulation and environmental protection |
| 40113-02 | Connector protector kit for 3300 XL 8 mm probes and extension cables |
| 136536-01 | Connector protector adapter for pre-1998 installation tool compatibility |
| 40180-02 | Set of 10 pairs connector protectors for 3300 XL probe cable systems |
| 03839410 | 75Ω triaxial male connector protector for environmental sealing |
| 03839420 | 75Ω triaxial female connector protector for probe and extension cable protection |
| 04301007 | 3/8-24 probe lock nut with safety wire holes for secure mounting |
| 04301008 | M10 x 1 probe lock nut with safety wire holes for probe fixation |
| 330153-01 | 3300 XL connector kit with ClickLoc connectors and installation accessories |
| 330153-09 | ETR version connector kit for high-temperature 3300 XL probe systems |
| 163356 | Connector crimp tool kit for ClickLoc connector installation and assembly |
