Bently Nevada 330130-030-00-00 3300 XL Standard Extension Cable Ready For Ship

Bently Nevada 330130-030-00-00 3300 XL Standard Extension Cable Ready For Ship

Product Name:3300 XL Standard Extension Cable

Brand Name:Bently Nevada

Model Number:330130-030-00-00

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330130 030 00 00 3300 xl standard extension cable ready for ship-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330130-030-00-00
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	330130-030-00-00
Product Name	3300 XL Standard Extension Cable
Manufacturer	Bently Nevada
Product Type	Proximity Transducer Extension Cable
Compatible System	3300 XL 8 mm Proximity Transducer System
Cable Length	3.0 m (9.8 ft)
Cable Type	Standard 75 Ω Triaxial FEP Insulated Cable
Connector Type	Gold-plated ClickLoc Connectors
Connector Option	Standard Cable (Option 00)
Agency Approval	None Required (Option 00)
Typical Capacitance	69.9 pF/m
Minimum Bend Radius	25.4 mm (1.0 in)
Operating Temperature	-52°C to +177°C
Storage Temperature	-52°C to +177°C
Extension Cable Resistance	0.66 ± 0.10 Ω
Jacket Resistance	0.20 ± 0.04 Ω
Maximum Field Wiring	305 m (1000 ft)
Compatible Probe	3300 XL 8 mm Proximity Probe
Compatible Sensor	3300 XL Proximitor Sensor
Dimension	Cable Length: 3.0 m (9.8 ft)
Weight	Approx. 34 g/m (Typical)

Description

Bently Nevada 330130-030-00-00 is a 3300 XL Standard Extension Cable engineered for use with the 3300 XL 8 mm Proximity Transducer System. Designed to deliver dependable signal transmission between the proximity probe and Proximitor sensor, this 3-meter extension cable helps maintain accurate vibration, shaft position, and speed monitoring in rotating machinery applications.

As part of the 3300 XL, 3300 XL 8 mm, and 3300 Series monitoring platform, 330130-030-00-00 provides excellent electrical compatibility, stable impedance characteristics, and reliable long-distance performance. Its durable FEP-insulated triaxial cable construction minimizes signal loss while supporting interchangeability with compatible Bently Nevada system components.

Built for demanding industrial environments, 330130-030-00-00 offers corrosion-resistant connectors, flexible installation, and long service life. It is widely applied in turbines, compressors, pumps, generators, and other critical assets where continuous condition monitoring and predictive maintenance are essential for maximizing equipment availability.

Applications

Power plants: Provides reliable extension between proximity probes and monitoring systems for turbine vibration, shaft position, and generator protection.
Substations: Supports rotating auxiliary equipment monitoring, improving operational reliability and predictive maintenance.
Chemical plants: Enables continuous vibration measurement for pumps, compressors, and process equipment operating in hazardous environments.
Steel mills: Delivers stable signal transmission for rolling mills, large motors, and high-speed rotating machinery exposed to vibration and EMI.
Machinery manufacturing plants: Integrates with automated machinery, test benches, compressors, and industrial drive systems for precise condition monitoring.

Features

High-quality 75 Ω triaxial FEP insulated cable for stable signal transmission.
Designed specifically for the 3300 XL 8 mm Proximity Transducer System.
Standard 3-meter cable length for flexible installation.
Corrosion-resistant gold-plated ClickLoc connectors.
Excellent RFI/EMI resistance for industrial environments.
Fully interchangeable with compatible 3300 XL components.
Durable construction suitable for long-term continuous operation.
Supports predictive maintenance and machinery protection systems.

Functions

Transmits proximity probe signals with minimal attenuation and excellent accuracy.
Maintains stable electrical characteristics throughout the complete transducer system.
Connects the proximity probe to the Proximitor sensor for vibration monitoring.
Supports shaft displacement, radial vibration, axial position, and speed measurement applications.
Reduces installation complexity through plug-and-play ClickLoc connectors.
Provides reliable operation under demanding industrial temperatures and harsh environments.
Enhances machine condition monitoring by ensuring consistent sensor communication.
Compatible with turbines, compressors, pumps, generators, motors, and other critical rotating equipment.
Helps improve predictive maintenance efficiency while reducing unexpected equipment downtime.

FAQ

Q1: What is the primary function of 330130-030-00-00?
A1: It extends the connection between a 3300 XL proximity probe and the Proximitor sensor while maintaining accurate signal transmission.

Q2: Which monitoring system is 330130-030-00-00 designed for?
A2: It is designed for the Bently Nevada 3300 XL 8 mm Proximity Transducer System.

Q3: What is the cable length of 330130-030-00-00?
A3: The standard cable length is 3.0 meters (9.8 feet).

Q4: Does 330130-030-00-00 support industrial environments?
A4: Yes. Its FEP-insulated triaxial cable and corrosion-resistant connectors are engineered for demanding industrial applications.

Q5: Can 330130-030-00-00 be used with other 3300 XL components?
A5: Yes. It is fully compatible with matching 3300 XL probes and Proximitor sensors when configured with the correct total system length.

Spares

Number	Description
148722-01	3300 XL Test Plug with three color-coded 1-meter leads and banana plugs for testing Proximitor Sensor performance without disconnecting field wiring.
04310310	3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor installation.
03200006	Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors.
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools.
136536-01	Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors.
40180-02	Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables.
03839410	75Ω triaxial male connector protector for extension cable connections, providing environmental protection against moisture and contaminants.
03839420	75Ω triaxial female connector protector for probe and extension cable connections, providing environmental sealing and connector protection.
04301007	3/8-24 probe lock nut with dual safety-wire holes for secure probe mounting in vibration-prone applications.
04301008	M10 × 1 probe lock nut with dual safety-wire holes for secure installation and retention of proximity probes.
330153-01	3300 XL Connector Kit containing male and female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for cable termination and maintenance.
