Bently Nevada Cables

Overview

Brand Name:	Bently Nevada
Model Number:	330130-085-00-05
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model:	330130-085-00-05, 3300 XL Standard Extension Cable with 8.5 m cable length and CSA/ATEX/IECEx approvals.
Product Type:	Industrial eddy-current proximity transducer extension cable designed for Bently Nevada 3300 XL 8 mm monitoring systems.
Cable Length:	8.5 m (27.9 ft), used together with compatible probes to achieve the required total system length.
Cable Construction:	75 Ω triaxial FEP-insulated cable providing stable impedance, low signal loss, and excellent electrical performance.
Connector Type:	Gold-plated ClickLoc connectors ensure secure, corrosion-resistant, tool-free installation and reliable long-term connections.
Agency Approval:	CSA, ATEX, IECEx certified for hazardous industrial environments (Option 05).
Compatibility:	Fully compatible with 3300 XL 8 mm probes, 3300 XL Proximitor Sensors, and interchangeable with other qualified 3300 XL components.
Electrical Characteristics:	Typical capacitance 69.9 pF/m, optimized for high-frequency vibration and displacement signal transmission.
Minimum Bend Radius:	25.4 mm (1.0 in), allowing flexible routing while maintaining cable integrity.
Operating Temperature:	-52°C to +177°C (standard cable), suitable for demanding industrial applications.
Dimension:	Overall cable length 8.5 m (27.9 ft), flexible triaxial construction with industrial-grade connectors.
Weight:	Approx. 34 g/m, total cable weight approximately 0.29 kg (excluding packaging).

Description

330130-085-00-05 is a standard 8.5 m extension cable designed for the Bently Nevada 3300 XL 8 mm Proximity Transducer System. When paired with compatible 3300 XL probes and 3300 XL Proximitor Sensors, it forms a complete non-contact measurement solution for accurate shaft vibration, axial position, speed, and Keyphasor® reference monitoring. The cable is engineered to maintain precise signal transmission while ensuring total system length compliance.

Built with a durable 75 Ω triaxial FEP-insulated cable, 330130-085-00-05 features corrosion-resistant gold-plated ClickLoc connectors that simplify installation and provide reliable long-term electrical connections. The standard cable design offers excellent resistance to industrial vibration, electromagnetic interference, and demanding operating environments. It is fully interchangeable with compatible 3300 XL 8 mm system components without requiring individual calibration.

Compatible with models including 330130-030-00-05, 330130-060-00-05, 330130-070-00-05, and 330130-085-00-05, this extension cable is widely deployed in power generation, oil & gas, petrochemical, mining, and heavy industrial facilities. Its robust construction, certified hazardous-area approvals, and dependable signal integrity make it an excellent choice for predictive maintenance and critical rotating machinery protection.

Applications

Power plants: Provides accurate turbine shaft vibration, rotor position, and generator condition monitoring for predictive maintenance.
Oil & gas facilities: Supports rotating equipment protection systems including compressors, pumps, and gas turbines operating in hazardous locations.
Petrochemical plants: Ensures stable proximity signal transmission for critical machinery monitoring and process reliability.
Steel mills: Delivers dependable performance in environments exposed to vibration, heat, and strong electromagnetic interference.
Mining operations: Monitors heavy rotating equipment to reduce unexpected downtime and improve equipment availability.
Paper mills: Enables continuous condition monitoring of high-speed rolls, motors, and process machinery.
Machinery manufacturing plants: Integrates with automated production equipment for precision displacement and vibration measurement.
Marine and offshore platforms: Suitable for engine, compressor, and propulsion monitoring requiring certified industrial reliability.

Technical Data Summary

Supports complete 3300 XL 8 mm Proximity Transducer System configurations.
Designed for total system lengths that comply with Bently Nevada calibration requirements.
Standard 75 Ω triaxial FEP cable minimizes signal attenuation.
Typical cable capacitance of 69.9 pF/m supports accurate dynamic measurements.
Gold-plated ClickLoc connectors improve electrical reliability and simplify installation.
Compatible with vibration, displacement, axial position, speed, and Keyphasor® applications.
Full interchangeability with qualified 3300 XL extension cables and probes.
Suitable for field wiring distances up to 305 m (1000 ft) between sensor and monitor.
Certified for installation in hazardous industrial environments.
Optimized for long-term machine condition monitoring and predictive maintenance programs.

Environmental Strength

Operates reliably from -52°C to +177°C under standard environmental conditions.
Resistant to industrial vibration, moisture, and common process contaminants.
Excellent immunity against electromagnetic interference (EMI) and radio frequency interference (RFI).
Corrosion-resistant gold-plated connectors improve durability in harsh environments.
Flexible cable construction maintains performance under repeated installation and routing.
CSA, ATEX, and IECEx certifications support hazardous-area deployment.
Suitable for continuous operation in power generation, petrochemical, mining, and offshore industries.
Engineered for dependable long-term operation with minimal maintenance requirements.

FAQ

Q1: What is the primary purpose of the 330130-085-00-05 extension cable?
A1: It extends the connection between the 3300 XL proximity probe and Proximitor Sensor while maintaining the required calibrated system length for accurate vibration and position measurements.

Q2: Is the 330130-085-00-05 compatible with all 3300 XL 8 mm systems?
A2: Yes. It is designed for use with compatible 3300 XL 8 mm probes and Proximitor Sensors and supports full system interchangeability.

Q3: Can this extension cable be installed in hazardous industrial environments?
A3: Yes. The 330130-085-00-05 includes CSA, ATEX, and IECEx approvals, making it suitable for certified hazardous-area applications.

Q4: What cable material is used in the standard version?
A4: The cable uses a 75 Ω triaxial FEP-insulated construction with gold-plated ClickLoc connectors for stable signal transmission and long service life.

Q5: Which industries commonly use the 330130-085-00-05?
A5: It is widely used in power generation, oil and gas, petrochemical processing, mining, marine, and other industries requiring continuous rotating machinery condition monitoring.

Spares

Number	Description
148722-01	3300 XL Test Plug with three color-coded 1-meter leads and banana plugs for testing Proximitor Sensor performance without disconnecting field wiring.
04310310	3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor installation.
03200006	Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors.
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools.
136536-01	Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors.
40180-02	Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables.
03839410	75Ω triaxial male connector protector for extension cable connections, providing environmental protection against moisture and contaminants.
03839420	75Ω triaxial female connector protector for probe and extension cable connections, providing environmental sealing and connector protection.
04301007	3/8-24 probe lock nut with dual safety-wire holes for secure probe mounting in vibration-prone applications.
04301008	M10 × 1 probe lock nut with dual safety-wire holes for secure installation and retention of proximity probes.
330153-01	3300 XL Connector Kit containing male and female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for cable termination and maintenance.
