Bently Nevada 330173-00-05-10-12-00 3300 5mm Proximity Probes Ready For Ship

Bently Nevada 330173-00-05-10-12-00 3300 5mm Proximity Probes Ready For Ship

Product Name:3300 5mm Proximity Probes

Brand Name:Bently Nevada

Model Number:330173-00-05-10-12-00

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330173 00 05 10 12 00 3300 5mm proximity probes ready for ship-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330173-00-05-10-12-00
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	330173-00-05-10-12-00
Product Type	3300 5 mm Proximity Probe
Thread Size	M8 x 1
Cable Type	FluidLoc cable
Total Length	1.0 meter
Linear Range	2 mm (80 mils)
Frequency Response	0 to 10 kHz
Recommended Gap Setting	1.27 mm (50 mils)
Probe Tip Material	Polyphenylene Sulfide (PPS)
Probe Case Material	AISI 303/304 Stainless Steel
Operating Temperature	-35°C to +177°C
Minimum Shaft Diameter	50.8 mm
Connector Type	Miniature coaxial ClickLoc
Dimension	1.3x1.1x120cm
Weight	0.04kg

Description

330173-00-05-10-12-00 is a compact eddy current proximity probe from the Bently Nevada 3300 Series, engineered for accurate shaft vibration and position monitoring in rotating machinery. Designed with an M8 x 1 threaded stainless-steel body and FluidLoc cable construction, this model delivers stable signal transmission and enhanced resistance against oil ingress in harsh industrial environments.

The 330173-00-05-10-12-00 proximity transducer system operates together with a 3300 XL extension cable and Proximitor sensor to provide highly reliable non-contact measurement for turbines, compressors, pumps, and motors. Its compact 5 mm probe structure is ideal for installations with limited mounting space where larger 8 mm probes cannot be accommodated.

With robust PPS probe-tip encapsulation, corrosion-resistant ClickLoc connectors, and excellent temperature stability, 330173-00-05-10-12-00, 330174, and other 3300 Series probes are widely used in power generation, petrochemical processing, steel manufacturing, and machinery automation systems requiring continuous vibration protection and condition monitoring.

Applications

Power plants: Used for turbine shaft vibration monitoring, generator protection, and overspeed measurement systems.
Substations: Supports rotating equipment condition monitoring and auxiliary machinery diagnostics.
Chemical plants: Enables reliable process equipment vibration feedback in hazardous industrial areas.
Steel mills: Performs stable vibration and position sensing under high-temperature and heavy EMI conditions.
Machinery manufacturing plants: Applied in compressors, pumps, motors, automated production lines, and packaging systems.

Features

Compact 5 mm probe design for tight installation spaces
FluidLoc cable option helps prevent oil leakage
High vibration measurement accuracy and stable output
Corrosion-resistant gold-plated ClickLoc connectors
Strong PPS probe-tip encapsulation for durability
Wide operating temperature capability
Compatible with 3300 XL extension cables and Proximitor sensors
Excellent EMI/RFI resistance for industrial environments

Functions

Non-contact shaft vibration monitoring
Rotor axial position measurement
Speed sensing and Keyphasor signal acquisition
Continuous machine condition monitoring
Dynamic and static displacement detection
Turbine and compressor protection support
Industrial predictive maintenance integration

FAQ

Q1: What is the main function of the 330173-00-05-10-12-00 probe?
A1: It is designed for non-contact vibration and shaft position monitoring in rotating machinery.

Q2: Can the 330173-00-05-10-12-00 operate in high-temperature environments?
A2: Yes, the probe supports operating temperatures up to +177°C.

Q3: Is this probe compatible with 3300 XL systems?
A3: Yes, it works with 3300 XL extension cables and Proximitor sensors.

Q4: What is the benefit of the FluidLoc cable option?
A4: FluidLoc technology helps prevent oil and liquid migration through the cable interior.

Q5: Where is the 330173-00-05-10-12-00 commonly used?
A5: It is widely applied in turbines, compressors, pumps, motors, and industrial automation equipment.

Spares

Number	Describe
02120015	Bulk field wire, 1.0 mm² (18 AWG) 3-conductor twisted shielded cable designed for reliable connections between Proximitor sensors and monitoring systems in industrial environments.
03200006	Silicone self-fusing tape, 9.1-meter roll providing electrical insulation and environmental protection for industrial connector assemblies.
40113-03	Connector protector kit for 3300 5 mm probes, including connector protectors and installation tools for enhanced cable connection protection.
136536-01	Connector protector adapter designed to make older connector protector kits compatible with ClickLoc extension cable connectors.
40180-03	Package containing 10 pairs of 75Ω coaxial connector protectors for environmental sealing and cable protection.
03839410	75Ω triaxial/95Ω coaxial male connector protector for extension cable environmental protection and secure connector performance.
03800001	75Ω coaxial female connector protector designed for 3300 5 mm probe leads to improve environmental resistance and connector reliability.
163356	Connector crimp tool kit including multi-connector inserts and installation tools for ClickLoc connector assembly and maintenance applications.
