Bently Nevada 330190-040-01-00 3300 XL Extended Temperature Range (ETR) Extension Cable Original new

Bently Nevada 330190-040-01-00 3300 XL Extended Temperature Range (ETR) Extension Cable Original new

Product Name:3300 XL Extended Temperature Range (ETR) Extension Cable

Brand Name:Bently Nevada

Model Number:330190-040-01-00

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330190 040 01 00 3300 xl extended temperature range etr extension cable original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Environmental Strength
High-Resolution Measurement
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330190-040-01-00
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	330190-040-01-00
Product Type	Extended Temperature Range (ETR) Extension Cable
Compatible System	3300 XL 8 mm Proximity Transducer System
Cable Length	4.0 m (13.1 ft)
Cable Type	Armored cable
Cable Construction	75 Ω triaxial cable with PFA insulation
Maximum Operating Temperature	Up to 260°C (500°F)
Minimum Operating Temperature	-52°C (-62°F)
Connector Type	Gold-plated ClickLoc corrosion-resistant connectors
Minimum Bend Radius	25.4 mm (1.0 in)
Capacitance	Typical 69.9 pF/m
Agency Approval	Standard version (No approval option)
Dimensions	Overall cable length: 4.0 m (13.1 ft), minimum bend radius 25.4 mm (1.0 in)
Weight	Approx. 0.41 kg (armored cable, typical 103 g/m)

Description

Bently Nevada 330190-040-01-00 is an Extended Temperature Range (ETR) extension cable engineered for the 3300 XL 8 mm Proximity Transducer System, providing reliable signal transmission in demanding industrial environments. Designed with a 4.0 m cable length and armored construction, it supports continuous operation where elevated temperatures, vibration, and mechanical stress are common.

Compatible with 3300 XL Proximity Probes, 3300 XL Proximitor Sensors, and other 330190 series extension cables, the 330190-040-01-00 maintains accurate displacement and vibration measurements while ensuring dependable system performance. Its rugged materials and corrosion-resistant connectors simplify installation and improve long-term reliability.

This extension cable is widely selected for rotating machinery protection, turbine monitoring, compressors, pumps, and critical process equipment where measurement stability, durability, and seamless compatibility are essential for predictive maintenance programs.

Applications

Power plants: Connects proximity probes for turbine, generator, and rotating equipment vibration monitoring under elevated operating temperatures.
Oil & gas facilities: Supports compressors, pumps, and gas turbines requiring dependable displacement signal transmission in hazardous process environments.
Petrochemical plants: Enables continuous machinery protection systems exposed to high temperatures, oil, and process vibration.
Steel mills: Maintains stable sensor communication for rolling mills, heavy motors, and high-temperature production equipment.
Mining operations: Provides durable monitoring connections for crushers, conveyors, and large rotating machinery operating under severe mechanical stress.
Marine propulsion systems: Assists shaft vibration and position monitoring for propulsion equipment and auxiliary machinery.

Environmental Strength

Operates reliably across an extended temperature range from -52°C to 260°C for demanding industrial applications.
PFA-insulated triaxial cable offers excellent resistance to heat, chemicals, and long-term aging.
Stainless-steel armored construction protects against abrasion, crushing, and mechanical impact.
Gold-plated connectors resist corrosion and maintain low-contact resistance in humid environments.
Suitable for installations exposed to vibration, oil mist, dust, and industrial contaminants.
Flexible cable design maintains dependable performance while meeting minimum bend-radius requirements.

High-Resolution Measurement

Delivers stable signal transmission for accurate shaft displacement and vibration monitoring.
Supports precise operation with the 3300 XL 8 mm Proximity Transducer System for critical machinery protection.
Preserves measurement linearity across extended operating temperatures.
Low cable capacitance helps minimize signal attenuation and electromagnetic interference.
Compatible with high-frequency vibration measurements up to 10 kHz system response capability.
Maintains reliable communication between probe and Proximitor sensor for predictive maintenance applications.
Enhances machine condition monitoring by providing consistent, repeatable sensor performance in demanding industrial environments.

FAQ

Q1: What is the primary function of the 330190-040-01-00 extension cable?
A1: It connects a 3300 XL proximity probe to a Proximitor sensor while maintaining accurate vibration and displacement signal transmission.

Q2: Is the 330190-040-01-00 suitable for high-temperature environments?
A2: Yes. Its Extended Temperature Range design supports operating temperatures up to 260°C (500°F).

Q3: Which systems are compatible with the 330190-040-01-00?
A3: It is designed for use with the Bently Nevada 3300 XL 8 mm Proximity Transducer System, including compatible probes and Proximitor sensors.

Q4: What advantages does the armored cable version provide?
A4: The armored construction improves resistance to abrasion, vibration, mechanical impact, and harsh industrial conditions.

Q5: Does the extension cable require special calibration after installation?
A5: No. When used with compatible 3300 XL components, it supports direct installation without individual cable calibration, simplifying maintenance and system integration.

Spares

Number	Description
148722-01	3300 XL Test Plug with three color-coded 1-meter leads and banana plugs for testing Proximitor Sensor performance without disconnecting field wiring.
04310310	3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor installation.
03200006	Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors.
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools.
136536-01	Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors.
40180-02	Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables.
03839410	75Ω triaxial male connector protector for extension cable connections, providing environmental protection against moisture and contaminants.
03839420	75Ω triaxial female connector protector for probe and extension cable connections, providing environmental sealing and connector protection.
04301007	3/8-24 probe lock nut with dual safety-wire holes for secure probe mounting in vibration-prone applications.
04301008	M10 × 1 probe lock nut with dual safety-wire holes for secure installation and retention of proximity probes.
330153-01	3300 XL Connector Kit containing male and female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for cable termination and maintenance.
