Bently Nevada 330194-05-13-50-05 3300 XL 8 mm Extended Temperature Range Proximity Probes Original new

Bently Nevada 330194-05-13-50-05 3300 XL 8 mm Extended Temperature Range Proximity Probes Original new

Product Name:3300 XL 8 mm Extended Temperature Range Proximity Probes

Brand Name:Bently Nevada

Model Number:330194-05-13-50-05

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330194 05 13 50 05 3300 xl 8 mm extended temperature range proximity probes original new-1

Overview
Inquiry now
Specifications
Description
Applications
Technical Data Summary
Environmental Strength
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330194-05-13-50-05
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Inquiry now

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model:	330194-05-13-50-05, armored 3300 XL 8 mm Extended Temperature Range proximity probe with 5 m system configuration.
Manufacturer:	Bently Nevada, specialized in industrial machinery condition monitoring and protection solutions.
Probe Type:	Non-contact eddy current proximity probe with M10 × 1 metric thread and armored cable.
Measurement Function:	Shaft vibration, axial position, rotor displacement, Keyphasor reference, and speed monitoring.
Measuring Range:	Linear range of 0.25 mm to 2.30 mm with high repeatability and measurement stability.
Output Sensitivity:	7.87 V/mm (200 mV/mil) nominal incremental scale factor.
Operating Temperature:	Probe tip up to +218°C, probe cable up to +260°C for extended temperature applications.
Dimension:	M10 × 1 threaded probe body, approximately 130 mm case length, 5.0 m total system length.
Weight:	Probe approximately 323 g, complete monitoring system approximately 0.7 kg, armored cable approximately 103 g/m.

Description

The 330194-05-13-50-05 is an armored Bently Nevada 3300 XL 8 mm Extended Temperature Range (ETR) proximity probe designed for continuous shaft vibration and position monitoring in mission-critical rotating equipment. As a member of the 330194 and 330193 probe family, it combines non-contact eddy current sensing technology with a rugged stainless steel construction for dependable performance in demanding industrial environments.

Working seamlessly with the 3300 XL Proximitor Sensor and compatible extension cables, the 330194-05-13-50-05 delivers accurate displacement signals without requiring individual probe matching or field calibration. Its modular architecture simplifies installation while maintaining excellent compatibility across the 3300 XL monitoring platform.

With a 5-meter system configuration, extended temperature capability, API 670 compliance, and international hazardous-area approvals, the 330194-05-13-50-05 provides a reliable solution for predictive maintenance, machinery protection, and condition monitoring in power generation, petrochemical processing, oil & gas, and heavy industrial applications.

Applications

Power plants: Used for steam turbine vibration monitoring, generator shaft position measurement, and rotating equipment protection.
Substations: Supports monitoring of auxiliary rotating equipment for stable operation and preventive maintenance.
Chemical plants: Provides reliable vibration and displacement measurement for pumps, compressors, and process machinery.
Steel mills: Performs continuous equipment monitoring in high-temperature, dusty, and high-EMI production environments.
Machinery manufacturing: Applied to automated production lines, CNC equipment, robotic systems, and industrial testing machines.
Oil & gas facilities: Protects compressors, gas turbines, pumps, and critical rotating assets with continuous condition monitoring.
Marine industry: Monitors propulsion equipment and auxiliary machinery operating under harsh offshore conditions.

Technical Data Summary

Sensing Technology: Non-contact eddy current measurement for precise shaft vibration and displacement monitoring.
Linear Measurement Range: 0.25 mm to 2.30 mm with excellent linearity and repeatable performance.
Sensitivity: Standard output of 7.87 V/mm (200 mV/mil) for accurate condition monitoring.
System Configuration: 5-meter system designed for use with compatible 5 m 3300 XL Proximitor sensors.
Mechanical Construction: Stainless steel armored cable improves resistance to abrasion, oil contamination, and mechanical stress.
Installation: M10 × 1 threaded design enables secure installation in turbines, compressors, and industrial rotating equipment.
Compatibility: Fully interchangeable with matching Bently Nevada 3300 XL monitoring components.

Environmental Strength

Extended Temperature Performance: Probe tip withstands temperatures up to +218°C, while the ETR cable supports up to +260°C.
EMI/RFI Protection: High resistance to electromagnetic and radio-frequency interference ensures stable signal quality.
Industrial Durability: Stainless steel housing and gold-plated ClickLoc connectors provide excellent corrosion resistance and long service life.
Hazardous Area Operation: Certified for CSA, ATEX, and IECEx applications, suitable for explosive industrial environments.
Environmental Compliance: Meets EMC, RoHS, FCC, and API 670 requirements for industrial machinery monitoring.
Continuous Reliability: Designed for long-term operation in vibration-intensive, humid, dusty, and oil-exposed industrial installations.

FAQ

Q1: What is the primary purpose of the 330194-05-13-50-05?
A1: It is designed for non-contact measurement of shaft vibration, axial position, and rotational speed in critical rotating machinery.

Q2: Does the 330194-05-13-50-05 require field calibration?
A2: No. It is designed for direct interchangeability with compatible 3300 XL components without individual field calibration.

Q3: Is this model suitable for high-temperature applications?
A3: Yes. The ETR version supports probe temperatures up to +218°C and cable temperatures up to +260°C.

Q4: Which industries commonly use this proximity probe?
A4: It is widely applied in power generation, oil & gas, petrochemical, steel production, marine, and industrial manufacturing.

Q5: What certifications are available for this product?
A5: Depending on the configuration, it supports CSA, ATEX, IECEx, EMC, RoHS, FCC, and API 670 compliance for industrial applications.

Spares

Number	Description
148722-01	3300 XL Test Plug with three color-coded 1-meter leads and banana plugs for testing Proximitor Sensor performance without disconnecting field wiring.
04310310	3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor installation.
03200006	Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors.
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools.
136536-01	Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors.
40180-02	Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables.
03839410	75Ω triaxial male connector protector for extension cable connections, providing environmental protection against moisture and contaminants.
03839420	75Ω triaxial female connector protector for probe and extension cable connections, providing environmental sealing and connector protection.
04301007	3/8-24 probe lock nut with dual safety-wire holes for secure probe mounting in vibration-prone applications.
04301008	M10 × 1 probe lock nut with dual safety-wire holes for secure installation and retention of proximity probes.
330153-01	3300 XL Connector Kit containing male and female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for cable termination and maintenance.
