Overview

The Bently Nevada 330195-02-12-05-00 3300 XL 8 mm ETR Reverse Mount Proximity Probe is a high-precision eddy current sensor designed for accurate vibration and position measurement in fluid-film bearing machinery. As part of the extended temperature range (ETR) 3300 XL series, it is engineered for reliable operation in demanding industrial environments.

This reverse mount probe features D3/8-24 UNF threading, allowing secure installation in confined or angled locations where conventional probe mounting is difficult. It is designed to deliver stable performance and consistent measurement accuracy in both static and dynamic monitoring applications.

Fully integrated within the 3300 XL transducer system, the probe ensures compatibility and interchangeability with other system components without requiring recalibration.

Functions

Measures shaft vibration and axial/radial displacement using eddy current technology
Provides high-accuracy static (position) and dynamic (vibration) monitoring
Supports machinery protection and condition monitoring of rotating equipment
Enables installation in reverse-mount or space-constrained configurations
Transmits stable signals to 3300 XL Proximitor sensors and monitoring systems
Supports full system integration for industrial asset protection

Features

Extended Temperature Range (ETR) 8 mm eddy current proximity probe for harsh operating environments
Reverse mount design with D3/8-24 UNF thread for installation in confined or angled locations
Compact 0.5 m (1.6 ft) cable for flexible system integration
Stable electrical characteristics with 50 Ω output resistance and 7.45 ± 0.50 Ω probe DC resistance
High-temperature and low-temperature capability: probe tip up to 177°C, cable/connector up to 260°C
Durable construction using PPS probe tip and AISI 303/304 stainless steel housing
High mechanical strength with 22.6 N·m maximum torque rating on probe case
Reinforced reliability through TipLoc and CableLoc mechanical retention technologies
High pull strength design supporting up to 330 N (75 lbf) between probe and cable
Optional FluidLoc cable technology to prevent fluid ingress through the cable assembly
Fully compatible with the Bently Nevada 3300 XL 8 mm Proximity Transducer System
Interchangeable with other 3300 series components without requiring recalibration
Designed to meet API 670 compliance for industrial machinery monitoring systems

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Winnie
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Parameter

Product Name	Bently Nevada 330195-02-12-05-00 ETR Reverse Mount Proximity Probe
Manufacturer	Bently Nevada
Product Type	ETR Reverse Mount Proximity Probe
Part Number	330195-02-12-05-00
Estimated shipping dimensions	1.3x1.1x58cm
Weight	0.02kg
Place of shipment	Xiamen, China
Country of origin	USA
Total Length Option	0.5 meter (1.6 feet)
Agency Approval Option	Not required
Probe dc resistance (nominal) (RPROBE) table	7.45 ± 0.50 ohms
Probe Tip Material	Polyphenylene sulfide (PPS).
Probe Case Material	AISI 303 or 304 stainless steel (SST).
Operating and Storage Temperature	-51 °C to +177 °C (-60 °F to +351 °F) for the probe tip; -51 °C to +260 °C (-60 °F to +500 °F) for the probe cable and connector.

Application Scenarios

Fluid-film bearing vibration monitoring systems
Turbines, compressors, and rotating machinery diagnostics
Power generation and energy production equipment
Petrochemical and refinery rotating asset monitoring
High-temperature industrial environments requiring ETR probes
Space-constrained or reverse mounting installations
Critical machinery protection and predictive maintenance systems
Industrial automation and condition monitoring platforms

Operating Environment

The Bently Nevada 330195-02-12-05-00 3300 XL 8 mm ETR Reverse Mount Proximity Probe is designed for reliable performance in extreme industrial conditions, particularly in fluid-film bearing and rotating machinery applications where both high temperature and mechanical stress are present.

It supports extended temperature operation across the probe and cable assembly, with the probe tip capable of withstanding temperatures from –51°C to +177°C, and the cable and connector rated up to –51°C to +260°C, making it suitable for high-heat industrial zones.

The probe is engineered for harsh mechanical environments, maintaining structural integrity under high vibration, pressure variations, and continuous operation. Its robust stainless steel housing and reinforced cable construction ensure long-term durability in demanding machinery monitoring systems.

It is also suitable for environments exposed to industrial contaminants and fluids, with optional FluidLoc protection to prevent ingress, ensuring stable performance in oil-rich or process-intensive installations.
