Bently Nevada 330703-000-040-10-11-00 3300 XL 11 mm Proximity Probes In stock, China Bently Nevada 330703-000-040-10-11-00 3300 XL 11 mm Proximity Probes In stock Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	330703-000-040-10-11-00
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	330703-000-040-10-11-00
Probe Type	3300 XL 11 mm Proximity Probe
Thread Type	M14 × 1.5
Cable Type	FluidLoc Cable
Total Length	1.0 meter
Linear Range	4.0 mm (160 mils)
Frequency Response	0 to 8 kHz
Output Sensitivity	3.94 V/mm (100 mV/mil)
Recommended Gap Setting	2.5 mm (100 mils)
Probe Material	AISI 304 Stainless Steel
Probe Tip Material	Polyphenylene Sulfide (PPS)
Connector Type	Gold-plated ClickLoc Connector
Operating Temperature	-52°C to +177°C
Proximitor Sensor Temperature	-52°C to +100°C
Relative Humidity	100% Condensing
Probe Weight	Approx. 70 g (non-armored)
Proximitor Sensor Weight	Approx. 255 g
Minimum Bend Radius	25.4 mm
Dimension Reference	Overall case length 40 mm configuration
Compliance	CE, RoHS, SIL 2 / SIL 3

Description

Bently Nevada 330703-000-040-10-11-00 is a high-performance proximity transducer solution engineered for precise shaft vibration and axial displacement monitoring in demanding rotating machinery environments. As part of the 3300 XL 11 mm Proximity Transducer System, this model delivers stable non-contact measurement performance with enhanced linear range, making it suitable for turbines, compressors, pumps, and critical industrial assets requiring continuous condition monitoring.

Designed with a rugged M14 x 1.5 threaded probe body and advanced FluidLoc cable technology, 330703-000-040-10-11-00 helps prevent fluid ingress through the cable structure while improving long-term reliability in harsh oil and moisture environments. The integrated ClickLoc connector system ensures secure connections and reduces installation-related signal interruptions during operation.

Compared with traditional monitoring probes, 330703, 330704, 330709, and 330710 models provide improved EMI/RFI resistance, durable stainless-steel construction, and compatibility with modern Bently Nevada monitoring platforms including the 3500 Series. The extended linear measurement capability supports accurate radial vibration, thrust position, Keyphasor®, and differential expansion monitoring across high-speed industrial machinery applications.

Applications

Power plants: Used for turbine shaft vibration monitoring, thrust position detection, and generator protection systems.
Oil & gas facilities: Supports centrifugal compressor monitoring and rotating equipment predictive maintenance.
Chemical plants: Provides reliable non-contact displacement measurement in hazardous industrial environments.
Steel mills: Enables vibration supervision for high-speed rolling machinery exposed to heat and electromagnetic interference.
Machinery manufacturing plants: Integrated into automated rotating equipment, test benches, and industrial motor monitoring systems.
Marine industry: Applied in propulsion systems and offshore rotating machinery condition monitoring.
Paper mills: Used for continuous monitoring of large blower systems and critical process equipment.

Features

Long linear measurement range for accurate displacement monitoring
FluidLoc cable design minimizes oil contamination risks
Excellent EMI/RFI immunity for industrial environments
Durable stainless-steel probe housing construction
ClickLoc connector improves connection security
Compatible with Bently Nevada 3500 monitoring systems
Suitable for vibration, thrust, and Keyphasor® measurements
Supports harsh environments with high humidity tolerance

Functions

Monitors shaft radial vibration in rotating machinery
Measures axial thrust position with high accuracy
Detects differential expansion in turbine systems
Provides Keyphasor® reference signal generation
Supports zero-speed and phase reference applications
Enables predictive maintenance and machinery diagnostics
Improves operational reliability of critical assets

FAQ

Q1: What is the primary use of the 330703-000-040-10-11-00 probe?
A1: It is mainly used for non-contact vibration and displacement monitoring in rotating industrial machinery.

Q2: Is the 330703-000-040-10-11-00 compatible with Bently Nevada 3500 systems?
A2: Yes, it is fully compatible with updated Bently Nevada 3500 monitoring systems.

Q3: What advantages does the FluidLoc cable provide?
A3: FluidLoc technology helps prevent oil and liquid migration through the cable structure, improving reliability.

Q4: Can this probe operate in high-temperature environments?
A4: Yes, the probe supports operating temperatures up to +177°C.

Q5: What measurements can the 3300 XL 11 mm system perform?
A5: It supports radial vibration, axial position, differential expansion, Keyphasor®, and shaft displacement measurements.

Spares

Number	Describe
146255	3300XL 11 mm User Guide
144979	Performance Specification
02120015	Bulk field wire, 1.0 mm² (18 AWG), 3 conductor, twisted, shielded cable with drain wire, specify length in feet
02173009	Bulk field wire, 1.0 mm² (18 AWG), 3 conductor, twisted, shielded cable, specify length in feet
138492-01	Replacement panel-mount mounting pad
138493-01	Replacement DIN-mount mounting pad
01609137	BNC (F) to banana plugs
01609138	Proximitor connector test pin wiring with two test pins to BNC (F) connector
40971-04	50 Ω cable with two BNC (M) connectors for transducer system performance testing
04310310	3300XL Proximitor Sensor panel-mount screws, package includes four 6-32 UNC thread forming screws
03200006	Silicone self-fusing tape, 9.1 meter (10 yard) roll for connector protection and electrical isolation
40113-02	Connector Protector Kit for 3300 XL probes and extension cables
136536-01	Connector Protector Adapter compatible with previous 3300 connector protector kits
40180-02	Connector Protectors, package contains 10 pairs
03839410	Male Connector Protector for extension cable environmental protection
03839420	Female Connector Protector for probe lead and Proximitor Sensor connection protection
330153-01	3300 XL Connector Kit with ClickLoc connectors, sleeves, and silicone tape
163356	Connector Crimp Tool Kit with 75 Ω 3300 XL ClickLoc inserts and carrying case
