Product Name:3300 XL 11 mm Reverse Mount Probe
Brand Name:BENTLY NEVADA
Model Number:330705-02-18-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330705-02-18-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Product Model |
330705-02-18-10-02-00 |
|
Probe Type |
3300 XL 11 mm Proximity Probe |
|
Thread Type |
M14 x 1.5 |
|
System Output |
3.94 V/mm (100 mV/mil) |
|
Linear Range |
0.5 – 4.5 mm |
|
Frequency Range |
0 – 8 kHz |
|
Connector Type |
Miniature ClickLoc coaxial |
|
Cable Type |
Triaxial FEP insulated |
|
Material |
Stainless steel probe case |
|
Operating Temp |
-52°C to +177°C |
|
Probe Length |
1–9 m options |
|
Dimension |
1.2x1x122cm |
|
Weight |
0.05kg |
The330705-02-18-10-02-00is part of the Bently Nevada 3300 XL 11 mm proximity probe series, designed for high-accuracy, non-contact vibration and displacement monitoring in industrial machinery. It works as a key element within the 3300 XL transducer system, delivering stable performance for condition monitoring and shaft position measurement in rotating equipment.
As part of the3300 XL 11 mm probe family, including models such as330703,330704, and330706, this version features an M14 x 1.5 threaded configuration with ClickLoc connectors for secure installation. The armored structure improves mechanical durability and resistance to harsh industrial environments.
Engineered for turbine, compressor, and rotating machine applications, the330705-02-18-10-02-00provides reliable signal transmission, strong EMI resistance, and long-term stability, making it suitable for critical predictive maintenance systems.
Q1: What is the 330705-02-18-10-02-00 used for?
A1: It is used for non-contact vibration and shaft position measurement in rotating machinery systems.
Q2: Which system is compatible with this probe?
A2: It is fully compatible with the Bently Nevada 3300 XL 11 mm transducer system.
Q3: What industries commonly use this probe?
A3: It is widely used in power plants, refineries, steel mills, and industrial automation facilities.
Q4: Does the probe support harsh environments?
A4: Yes, its armored design and EMI-resistant structure ensure stable operation in harsh conditions.
Q5: What type of connector does it use?
A5: It uses a Miniature ClickLoc coaxial connector for secure and reliable installation.
| Number | Describe |
|---|---|
| 146255 | 3300XL 11 mm User Guide |
| 144979 | Performance Specification |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3 conductor, twisted, shielded cable with drain wire, specify length in feet |
| 02173009 | Bulk field wire, 1.0 mm² (18 AWG), 3 conductor, twisted, shielded cable, specify length in feet |
| 138492-01 | Replacement panel-mount mounting pad |
| 138493-01 | Replacement DIN-mount mounting pad |
| 01609137 | BNC (F) to banana plugs |
| 01609138 | Proximitor connector test pin wiring with two test pins to BNC (F) connector |
| 40971-04 | 50 Ω cable with two BNC (M) connectors for transducer system performance testing |
| 04310310 | 3300XL Proximitor Sensor panel-mount screws, package includes four 6-32 UNC thread forming screws |
| 03200006 | Silicone self-fusing tape, 9.1 meter (10 yard) roll for connector protection and electrical isolation |
| 40113-02 | Connector Protector Kit for 3300 XL probes and extension cables |
| 136536-01 | Connector Protector Adapter compatible with previous 3300 connector protector kits |
| 40180-02 | Connector Protectors, package contains 10 pairs |
| 03839410 | Male Connector Protector for extension cable environmental protection |
| 03839420 | Female Connector Protector for probe lead and Proximitor Sensor connection protection |
| 330153-01 | 3300 XL Connector Kit with ClickLoc connectors, sleeves, and silicone tape |
| 163356 | Connector Crimp Tool Kit with 75 Ω 3300 XL ClickLoc inserts and carrying case |
