Product Name:3300 XL 11 mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330709-000-070-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330709-000-070-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Details |
|---|---|
| Model | 330709-000-070-10-02-00 |
| Series | Bently Nevada 3300 XL 11 mm |
| Thread Type | M16 x 1.5 |
| Probe Type | Non-contact proximity probe |
| Output Sensitivity | 3.94 V/mm (100 mV/mil) |
| Linear Range | Up to 4.0 mm (typical system dependent) |
| Frequency Range | 0 – 8 kHz |
| Cable Type | Coaxial / armored optional |
| Operating Temp | -52°C to +177°C |
| Storage Temp | -52°C to +177°C |
| Dimension (Probe Length) | 70 mm (configurable range) |
| Cable Length | 1 m / 5 m / 9 m options |
| Weight | Approx. 170 g (varies by configuration) |
330709-000-070-10-02-00 is a Bently Nevada 3300 XL 11 mm proximity probe designed for high-precision vibration and position monitoring in industrial rotating machinery. Built for reliability in demanding environments, it supports accurate non-contact measurement of shaft displacement and axial movement in turbine and compressor systems.
As part of the 3300 XL 11 mm Proximity Transducer System, the 3300 XL 11 mm probe series delivers an extended linear range and stable signal output, making it ideal for applications requiring larger measurement travel. The M16 x 1.5 threaded design ensures secure installation with or without armored cable configurations.
Engineered for compatibility with 3300 XL extension cables and Proximitor sensors, this model enhances monitoring accuracy in power generation, petrochemical, and heavy machinery systems. It provides consistent performance in high-temperature and high-vibration environments, supporting predictive maintenance strategies and equipment protection.
Q1: What system is 330709-000-070-10-02-00 compatible with?
A1: It is designed for the Bently Nevada 3300 XL 11 mm proximity transducer system.
Q2: What is the main application of this probe?
A2: It is used for vibration, axial position, and shaft displacement measurement in rotating machinery.
Q3: Can this probe be used in harsh environments?
A3: Yes, it is suitable for high temperature, high vibration, and industrial EMI environments.
Q4: Does it support armored cable configurations?
A4: Yes, the probe is available with both armored and non-armored cable options.
Q5: What industries commonly use this model?
A5: It is widely used in power generation, petrochemical plants, steel mills, and manufacturing systems.
| Number | Describe |
|---|---|
| 40971-04 | 50 Ω cable with two BNC (M) connectors, used with adapter 01609137 and 01609138 for transducer system performance testing via Proximitor Sensor test pin holes. |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screws, includes four 6-32 UNC thread-forming mounting screws for standard 3300 XL Proximitor housings. |
| 03200006 | Silicone self-fusing tape, 9.1 m roll designed for connector insulation, environmental protection, and electrical isolation. |
| 40113-02 | Connector Protector Kit for 3300 XL probes and extension cables, includes protectors and installation tools for secure connection sealing. |
| 136536-01 | Connector Protector Adapter enabling compatibility between older connector protector kits and 3300 XL ClickLoc connector systems. |
| 40180-02 | Connector Protectors package containing 10 pairs, designed to provide environmental protection for probe and extension cable connections. |
| 03839410 | Male connector protector installed on extension cable, interfaces with female protector to ensure environmental sealing of connectors. |
| 03839420 | Female connector protector used on probe lead and extension cable, protects connectors from moisture, dust, and contamination. |
| 330153-01 | 3300 XL Connector Kit including male/female ClickLoc connectors, sleeves, and silicone tape for probe and extension cable assembly. |
| 163356 | Connector Crimp Tool Kit including 75 Ω ClickLoc inserts and installation instructions, supplied with a protective carrying case. |
