Product Name:3300 XL 50 mm Proximity Probe
Brand Name:Bently Nevada
Model Number:330876-02-50-01-00
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330876-02-50-01-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model | 330876-02-50-01-00 |
| System Type | 3300 XL 50 mm Proximity Transducer System |
| Probe Diameter | 1.99 in (50 mm housing) |
| Thread Options | 1/2-20, M14x1.5, side exit |
| Cable Length Options | 1.0 m / 5.0 m / 9.0 m |
| Operating Temperature | -35°C to +200°C (probe) |
| Output Scale Factor | 394 mV/mm (10 mV/mil) |
| Linear Range | Up to 27.9 mm |
| Material | Stainless steel / PPS / FluidLoc cable |
| Dimensions | Depends on configuration (probe + cable system) |
| Weight | Varies by cable length & mounting setup |
The 3300 XL 50 mm Proximity Transducer System with model 330876-02-50-01-00 is a high-performance eddy current monitoring solution designed for precise axial displacement and differential expansion measurement in large rotating machinery. It integrates advanced probe technology, extension cabling, and a dedicated Proximitor sensor to deliver stable, high-accuracy vibration and position data in demanding industrial environments.
As part of the Bently Nevada 3300 XL 50 mm Proximity Probe series, this system is engineered for turbine and generator monitoring applications where long linear range and high thermal resistance are critical. The large coil design ensures extended measurement capability with excellent signal stability.
Its rugged construction, FluidLoc cabling, and high-temperature resistance make it suitable for harsh steam turbine and heavy-duty rotating equipment environments.
Q1: What is the 3300 XL 50 mm Proximity Probe used for?
A1: It is used for measuring shaft displacement, differential expansion, and rotor movement in turbines and large rotating machinery.
Q2: Can the 330876-02-50-01-00 operate in high temperatures?
A2: Yes, the probe can continuously operate up to 200°C and withstand short-term peaks up to 250°C.
Q3: Is this system compatible with older 7200 series systems?
A3: Yes, it is designed as a direct upgrade with compatible mounting and output characteristics.
Q4: What industries commonly use this proximity system?
A4: It is widely used in power generation, petrochemical, steel manufacturing, and heavy machinery industries.
Q5: What makes the FluidLoc cable important?
A5: The FluidLoc design prevents moisture ingress, ensuring stable long-term performance in harsh environments.
| Number | Description |
|---|---|
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor, twisted, shielded cable with drain wire. Length to be specified in feet. |
| 02173009 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor, twisted, shielded cable. Length to be specified in feet. |
| 138492-01 | Replacement panel-mount mounting pad for industrial installation support. |
| 138493-01 | Replacement DIN-mount mounting pad designed for standard DIN rail applications. |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screws kit, includes four 6-32 UNC thread-forming mounting screws. |
| 03200006 | Silicone self-fusing tape, 9.1 m (10 yard) roll, provides electrical isolation and environmental protection for connectors. |
| 40180-02 | Connector Protectors kit, package contains 10 pairs of connector protection components. |
| 03839410 | Male connector protector used on extension cable for environmental sealing and connector protection. |
| 03839420 | Female connector protector used on probe lead or extension cable to protect Proximitor Sensor connections. |
| 330153-10 | 3300 XL 50 mm Connector Kit including male/female ClickLoc connectors, color-coded sleeves, and slit PFA tubing. |
| 163356 | Connector Crimp Tool Kit with multi-connector inserts and installation instructions, supplied in carrying case. |
| 173873 | High Temperature Cable Zip Ties made of PEEK material, rated for continuous operation up to 200°C. |
| 174804-01 | Side Exit Probe Adapter Kit for adapting side exit probes for 330187 Extended Range Verification Kit. |
