Product Name:3300 NSv Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330910-03-09-05-02-05
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330910-03-09-05-02-05 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Model |
330910-03-09-05-02-05 |
|
Series |
3300 XL NSv Proximity Probe |
|
Thread Type |
M10×1 |
|
Cable Type |
Armored coaxial cable |
|
Total Length |
0.5 m – 5.0 m options |
|
Linear Range |
1.5 mm (typical) |
|
Operating Temperature |
-52°C to +177°C |
|
Storage Temperature |
-52°C to +177°C |
|
Material |
Stainless steel + PPS tip |
|
Weight |
0.1kg |
|
Dimension |
2x66x1.6cm |
The 330910-03-09-05-02-05 — 3300 NSv Proximity Probe with armored M10×1 configuration is designed for compact machinery installations where space constraints and high-precision vibration monitoring are required. It is part of the Bently Nevada 3300 XL NSv series, optimized for small shaft and tight-clearance applications in industrial rotating equipment.
The 3300 NSv probe system (330910 series) delivers stable eddy current measurement performance for radial vibration, axial displacement, and speed sensing. Its armored cable structure improves mechanical durability and resistance to harsh industrial environments such as compressors and turbines.
When integrated with the NSv extension cable and Proximitor sensor, the system ensures reliable signal transmission, excellent EMI resistance, and long-term operational stability, making it suitable for mission-critical condition monitoring systems.
Q1: What is 330910-03-09-05-02-05 used for?
A1: It is used for vibration and position monitoring in rotating machinery with tight installation spaces.
Q2: Is the 3300 NSv probe suitable for compressors?
A2: Yes, it is widely used in centrifugal and process gas compressors.
Q3: Does the probe support armored cable protection?
A3: Yes, this model includes an armored cable option for harsh environments.
Q4: What signals can it measure?
A4: It measures radial vibration, axial position, and speed signals.
Q5: Is it compatible with other Bently Nevada systems?
A5: Yes, it works with NSv extension cables and Proximitor sensors in the 3300 XL system.
| Number | Describe |
|---|---|
| 147357 | 3300 XL NSv Proximitor User Guide |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, length specified in feet |
| 138492-01 | Replacement panel-mount mounting pad |
| 138493-01 | Replacement DIN-mount mounting pad |
| 01609137 | BNC (F) to banana plugs adapter |
| 01609138 | Proximitor connector test pin wiring (two test pins to BNC (F) connector) |
| 40971-04 | 50 Ω cable with two BNC (M) connectors for transducer system performance testing |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread forming mounting screw |
| 03200006 | Silicone self-fusing tape, 9.1 m roll for connector electrical insulation and environmental protection |
| 40113-03 | Connector Protector Kit for 3300 NSv probes and extension cables with installation tools |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools |
| 40180-03 | Connector protectors, package of 10 pairs for NSv probes and extension cables |
| 03800000 | Male connector protector for environmental sealing of extension cable connections |
| 03800001 | Female connector protector for probe lead and Proximitor sensor connection protection |
| 330153-05 | 3300 NSv connector kit including ClickLoc connectors, sleeves, and silicone tape |
| 163356 | Connector crimp tool kit with 75 Ω ClickLoc inserts and installation instructions |
