Product Name:3300 NSv Extension Cable
Brand Name:Bently Nevada
Model Number:330930-060-00-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330930-060-00-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Details |
|
Product Model |
330930-060-00-00 |
|
Product Type |
3300 XL NSv Extension Cable |
|
Cable Length |
6.0 meters (19.7 ft) |
|
Cable Type |
75 Ω coaxial, shielded |
|
Insulation Material |
FEP (Fluoroethylene Propylene) |
|
Connector Type |
ClickLoc gold-plated brass |
|
Armoring Option |
Stainless steel optional |
|
Capacitance |
69.9 pF/m typical |
|
Minimum Bend Radius |
25.4 mm |
|
Weight |
0.12kg |
|
Dimension |
23x23x2cm |
The330930-060-00-00is a precision3300 XL NSv extension cableengineered for reliable signal transmission within compact and high-restriction industrial machinery environments. It is part of the Bently Nevada NSv proximity transducer system, ensuring stable communication between the probe and Proximitor sensor for accurate vibration and position monitoring.
Designed for demanding industrial applications, the330930-060-00-00offers flexible configuration options including armored, FluidLoc, and connector-protected variants. These features enhance resistance against moisture, mechanical stress, and harsh process conditions, making it suitable for long-term operation in critical rotating equipment systems.
When used with the3300 NSv probeand3300 XL NSv Proximitor Sensor, the330930-060-00-00supports precise measurement of radial vibration, axial position, and Keyphasor signals. It is widely applied in compressors, turbines, and small-shaft machinery where installation space is limited but measurement accuracy is essential.
Q1: What is the main use of 330930-060-00-00?
A1: It is used as an extension cable in the Bently Nevada 3300 XL NSv transducer system.
Q2: What system is it compatible with?
A2: It works with the 3300 NSv probe and 3300 XL NSv Proximitor Sensor.
Q3: What is the cable length of this model?
A3: The 330930-060-00-00 has a 6.0 meter extension length.
Q4: Can it be used in harsh environments?
A4: Yes, it supports armored and FluidLoc options for industrial protection.
Q5: What signals does it support?
A5: It transmits vibration, axial position, and Keyphasor reference signals.
| number | describe |
|---|---|
| 147357 | 3300 XL NSv Proximitor User Guide |
| 02120015 | Bulk field wire. 1.0 mm² (18 AWG), 3 conductor, twisted, shielded cable with drain wire. Specify length in feet. |
| 138492-01 | Replacement panel-mount mounting pad |
| 138493-01 | Replacement DIN-mount mounting pad |
| 01609137 | BNC (F) to banana plugs |
| 01609138 | Proximitor Connector Test Pin wiring (two test pins to a BNC (F) connector) |
| 40971-04 | 50 Ω cable with two BNC (M) connectors used with adapter 01609137 and 01609138 for system performance testing via Proximitor Sensor test pins |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screws, includes 6-32 UNC thread forming screw for Proximitor housings |
| 03200006 | Silicone self-fusing tape, 9.1 m roll, provides insulation and environmental protection for connectors |
| 40113-03 | Connector Protector Kit for 3300 NSv probes and extension cables including installation tools |
| 136536-01 | Connector Protector Adapter enabling compatibility with older installation tools and 75 Ω ClickLoc connectors |
| 40180-03 | Connector Protectors, package contains 10 pairs for environmental sealing |
| 03800000 | Male connector protector for extension cable connection protection |
| 03800001 | Female connector protector for probe and Proximitor Sensor connection protection |
| 330153-05 | 3300 NSv Connector Kit including ClickLoc connectors, sleeves, and silicone tape |
