Product Name: Monitor Module
Brand Name: Bently Nevada
Model Number: 3500/40 125672-01
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Bently Nevada 3500/40 125672-01 Monitor Module |
| Manufacturer | Bently Nevada |
| Product Type | Monitor Module |
| Part Number | 3500/40 125672-01 |
| Weight | 0.9kg |
| Estimated shipping dimensions | 2.5x25.6x24cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Probe Excitation | -24V DC |
| Frequency Response | 0 to 10 kHz |
| Displacement | 0–200 mils (0–5 mm) |
| Gap Voltage | -2V to -18V DC |
| Accuracy | ±1% of full scale. |
| Operating Temperature | -30°C to +65°C (-22°F to +149°F) |
| Humidity | 5–95% RH (non-condensing) |
| Channels | 4 Channel Monitor |
| Terminations | Internal Terminations |
| Alarm Levels | Alert / Danger |
| Measurement | Dynamic & Static |
| Machinery Protection System Module | Machinery Health Monitoring |
| Condition Monitoring Hardware | Industrial Diagnostics Module |
| Eddy Current Sensor Module | Turbomachinery Monitoring Module |
| Shaft Displacement Monitor | Vibration Analysis Module |
| Industrial Monitoring Module | Proximity Probe Interface |
| Rotating Machinery Protection | High Reliability Monitoring Module |
| Asset Protection System Module | Industrial Sensor Interface |
| GE Bently Nevada Hardware | Condition-Based Maintenance Module |
| Internal Termination Module | Critical Equipment Protection Module |
The Bently Nevada 3500/40 125672-01 Monitor Module is part of the Bently Nevada 3500 machinery protection system. It is designed to interface with proximity probes and provide accurate measurement of shaft displacement and vibration in rotating machinery.
With four monitoring channels and support for both dynamic and static measurements, the module delivers precise condition monitoring for critical industrial equipment such as turbines, compressors, and motors. It plays a key role in machinery protection and predictive maintenance systems.
Proximity Signal Conversion
Converts probe signals into accurate displacement and vibration measurements for machinery monitoring.
4-Channel Monitoring
Provides four independent channels for multi-point vibration and shaft displacement measurement.
Dynamic & Static Measurement
Supports both dynamic vibration analysis and static gap measurement for comprehensive monitoring.
Alarm Monitoring System
Includes Alert and Danger alarm levels for early fault detection and equipment protection.
High-Frequency Response
Supports frequency response up to 10 kHz for accurate vibration signal capture.
Probe Excitation Supply
Provides -24V DC excitation for proximity probe operation.
Data Accuracy Control
Maintains ±1% full-scale accuracy for reliable measurement results.
Internal Termination Design
Uses internal terminations to simplify wiring and improve installation efficiency.
Compared with similar vibration monitoring modules, the 3500/40 125672-01 offers higher measurement precision, integrated alarm functions, and robust industrial design for critical machinery protection.
High Measurement Accuracy: Delivers ±1% full-scale accuracy for reliable monitoring.
4-Channel Monitoring Capability: Supports multi-point vibration and displacement analysis.
Integrated Alarm System: Provides Alert and Danger thresholds for early fault detection.
Wide Frequency Response: Handles up to 10 kHz for detailed vibration analysis.
Dynamic and Static Measurement Support: Enables comprehensive machinery condition evaluation.
Robust Industrial Design: Suitable for harsh environments from -30°C to +65°C.
Simplified Installation:Internal terminations reduce wiring complexity and installation time.
What is 3500/40 125672-01 used for?
The 3500/40 125672-01 is used for vibration and shaft displacement monitoring in rotating machinery protection systems.
How many channels does 3500/40 125672-01 have?
The 3500/40 125672-01 provides four monitoring channels.
What type of measurements does 3500/40 125672-01 support?
The 3500/40 125672-01 supports both dynamic vibration and static displacement measurements.
What is the frequency response of 3500/40 125672-01?
The 3500/40 125672-01 supports a frequency response range of 0 to 10 kHz.
Does 3500/40 125672-01 include alarm functions?
Yes, the 3500/40 125672-01 includes Alert and Danger alarm levels for machinery protection.
What is the operating temperature range of 3500/40 125672-01?
The 3500/40 125672-01 operates from -30°C to +65°C.
What is the excitation voltage for 3500/40 125672-01?
The 3500/40 125672-01 provides -24V DC probe excitation.
