Product Name:Temperature Monitor
Brand Name:Bently Nevada
Model Number:3500/61E 285694-02
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
3500/61E 285694-02 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Description |
|---|---|
| Model | 3500/61E 285694-02 |
| Type | Temperature Monitoring Module |
| Channels | Up to 6 RTD inputs |
| Input Type | 100Ω Platinum / Nickel / Copper RTDs |
| Isolation | Non-isolated configuration |
| Power Consumption | ~5.6 W |
| Operating Temp | -20°C to +65°C |
| Storage Temp | -30°C to +85°C |
| Dimension | 228 × 50 × 289 mm |
| Weight | 1.23 kg |
| Output | Alarm + 4–20 mA recorder output |
| Mounting | 3500 Rack system compatible |
The 3500/61E 285694-02 is a non-isolated RTD temperature monitoring module designed for the Bently Nevada 3500 series condition monitoring platform. It supports up to six temperature input channels, enabling accurate multi-point thermal supervision of industrial machinery and process systems. As part of the 3500/61E family, it delivers stable signal acquisition and reliable alarm processing for critical asset protection applications.
The module conditions RTD signals and continuously compares measured values against user-configured alarm thresholds. Integrated with 3500 Rack Configuration Software, the 3500/61E allows flexible setup of temperature ranges, delays, and alarm logic, ensuring adaptable performance across different industrial environments.
Widely used in turbine systems, compressors, and rotating equipment, the 3500/61E 285694-02 provides robust temperature diagnostics for predictive maintenance strategies, improving equipment reliability and operational safety in demanding industrial applications.
Q1: What is 3500/61E 285694-02 used for?
A1: It is used for multi-channel RTD temperature monitoring in industrial machinery protection systems.
Q2: How many channels does the 3500/61E support?
A2: It supports up to 6 independent RTD input channels.
Q3: Is the 3500/61E compatible with RTD sensors?
A3: Yes, it supports platinum, nickel, and copper RTD sensor types.
Q4: Can alarm settings be configured?
A4: Yes, users can configure Alert and Danger thresholds via software.
Q5: What industries use the 3500/61E module?
A5: It is widely used in power plants, substations, chemical plants, and steel mills.
| Number | Description |
|---|---|
| 3500/61E 285694-02 | 6-channel non-isolated RTD temperature monitor module |
| 100M2179-01 | Temperature I/O module |
| 285694-01 | 3500/61E isolated TC version monitor |
| 285694-03 | 3500/67E isolated TC 2-channel monitor |
| 285694-04 | 3500/67E RTD non-isolated 2-channel monitor |
| 287547-01 | 3500/61E & 3500/67E instruction manual |
| 287199 | 18-pin jumper accessory for rack configuration |
