Product Name:Dual Hermetic Relays
Brand Name:Bently Nevada
Model Number:81546-01
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
81546-01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Product Model |
81546-01 Quad Relay Module |
|
System |
Bently Nevada 3300/45 Expansion Monitor |
|
Function |
Alarm relay switching module |
|
Relay Type |
Quad epoxy-sealed relay |
|
Input Signal |
Differential expansion channels |
|
Full-scale Range |
±0.25 mm to ±20 mm selectable |
|
Output Type |
Relay contact switching |
|
Power Consumption |
Approx. 1.5 W system dependent |
|
Operating Temperature |
0°C to +65°C |
|
Storage Temperature |
-40°C to +85°C |
|
Dimension |
5x10x22.8cm |
|
Weight |
0.34kg |
|
Installation |
Rack-mounted slot system |
|
Compatibility |
3300/45 expansion monitor system |
The 81546-01 Quad Relay Module is designed for integration within the Bently Nevada 3300/45 Dual Differential Expansion monitoring system. It supports reliable alarm relay switching for critical machinery protection applications in turbine and rotating equipment systems.
In the 3300/45 differential expansion monitoring platform, the 81546-01 enables quad relay output configuration, providing flexible alarm voting logic for multi-channel protection. It is used to ensure accurate response to axial rotor displacement and thermal expansion variations.
As part of the 3300 Series machinery protection architecture, the 81546-01 relay module enhances system safety by delivering stable switching performance, supporting industrial-grade monitoring of turbines, compressors, and high-speed rotating machinery.
Q1: What is the function of 81546-01 module?
A1: It provides quad relay output for alarm and protection functions in the 3300/45 system.
Q2: Is the 81546-01 compatible with all 3300/45 monitors?
A2: Yes, it is designed specifically for integration with the 3300/45 differential expansion monitor.
Q3: What type of relays does it use?
A3: It uses epoxy-sealed quad relay configuration for industrial reliability.
Q4: Can it be used in turbine monitoring systems?
A4: Yes, it is widely used in turbine and rotating machinery protection systems.
Q5: Does it support alarm voting logic?
A5: Yes, it supports relay-based alarm voting logic depending on system configuration.
| Number | Describe |
|---|---|
| 81544-01 | Dual epoxy-sealed relay module for 3300/45 system |
| 81545-01 | Dual hermetically sealed relay module for expansion monitoring |
| 81546-01 | Quad relay module for differential expansion protection system |
| 84152-01 | Spare quad relay assembly for Bently Nevada monitor system |
| 02245003 | External barrier accessory for signal protection |
| 02200406 | Surge protection module for TC signal lines |
| 02200408 | Surge protection module for RTD wiring systems |
