Product Name:monitoring module
Brand Name:BRAUN
Model Number:E1667.011
Country of Origin:Germany
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
BRAUN |
Model Number: |
E1667.011 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model | E1667.011 |
| Product Type | Safety Overspeed Monitoring Module |
| Safety Architecture | 2oo3 (Two-Out-of-Three Voting Logic) |
| Safety Integrity Level | SIL3 Certified |
| Standard Compliance | IEC 61508 |
| Trip Outputs | Trip Line I, II, III |
| Relay Logic | Safety Trip Relay Voting |
| Test Function | Automatic Speed Setpoint Verification |
| Supported Setpoints | SP1, SP1A, SP1B |
| Speed Test Range | Configurable ±5 RPM Verification |
| Monitoring Function | Overspeed and Safety Trip Monitoring |
| Application | Turbine and Rotating Machinery Protection |
| System Integration | Compatible with E1668 Monitoring Systems |
| Output Type | Safety Relay Output |
| Dimensions (Approx.) | 160 × 120 × 60 mm |
| Weight (Approx.) | 0.8 kg |
| Installation Type | Control Cabinet Mounting |
| Operating Environment | Industrial Safety Systems |
E1667.011 is a high-integrity safety monitoring module designed for critical overspeed protection and trip management applications in industrial rotating machinery systems. As part of the E1667 safety platform and commonly deployed alongside E1668 control modules, it utilizes advanced voting logic to improve operational reliability and minimize the risk of false shutdowns in safety-critical environments.
The E1667.011 supports 2oo3 (two-out-of-three) trip architecture through dedicated Trip Lines I, II, and III, enabling SIL3-rated safety functions in accordance with IEC 61508 requirements. By continuously evaluating trip relay status from multiple monitoring channels, the module provides dependable protection for turbines, compressors, generators, and other high-value assets.
Engineered for demanding industrial applications, E1667.011 also supports automated setpoint verification and speed-monitoring tests, helping operators validate safety performance while maintaining system availability and compliance with modern functional safety standards.
Q1: What is the primary function of the E1667.011 module?
A1: It provides SIL3-rated overspeed monitoring and safety trip protection for critical rotating machinery.
Q2: What does the 2oo3 voting logic mean?
A2: A trip action occurs when at least two out of three monitoring channels detect a fault condition.
Q3: Can the E1667.011 perform automatic safety testing?
A3: Yes, it supports automated verification of configured speed protection setpoints.
Q4: Which applications commonly use the E1667.011?
A4: It is widely used in turbines, compressors, generators, and other safety-critical rotating equipment.
Q5: What safety standard is supported by the E1667.011?
A5: The module supports SIL3 safety functions in accordance with IEC 61508 requirements.
