Product Name: AI Terminal Block
Brand Name: Emerson
Model Number: KJ3223X1-EA1 12P2867X022
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Commercial Terms
Minimum Order Quantity |
1 Piece |
Price |
Contact for Winnie |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Emerson KJ3223X1-EA1 12P2867X022 AI Terminal Block |
| Manufacturer | Emerson |
| Product Type | AI Terminal Block |
| Part Number | KJ3223X1-EA1 12P2867X022 |
| Weight | 0.1kg |
| Estimated shipping dimensions | 9x4.1x6.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Product Type | 16-CH AI Terminal Block |
| Input Power Rating | 30 VDC @ 100m A |
| Ambient Temperature | -40 °C to +70 °C |
| Shock | 10 g half-sine wave for 11 ms |
| Vibration | 1 mm peak to peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz |
| Airborne Contaminants | ISA-S71.04 –1985 Airborne; Contaminants Class G3 |
| Relative Humidity | 5 to 95% non-condensing |
The Emerson KJ3223X1-EA1 12P2867X022 is a 16-channel analog input (AI) terminal block designed for industrial automation and process control systems. It is used to collect and transmit analog field signals with high accuracy and stability, providing real-time process data for control and monitoring applications.
With its 16-channel architecture, the KJ3223X1-EA1 12P2867X022 enables simultaneous acquisition of multiple analog signals, making it suitable for large-scale industrial environments such as petrochemical plants, power generation facilities, metallurgy, and other process industries requiring continuous monitoring and precise control.
Engineered for harsh operating conditions, the module ensures stable performance across wide temperature ranges and challenging environmental conditions, supporting reliable long-term industrial operation.
Analog Signal Acquisition: Collects multiple analog input signals from field instruments and sensors for real-time process monitoring.
Multi-Channel Data Processing: Supports 16 input channels for simultaneous measurement and transmission of industrial process variables.
Process Monitoring Support: Provides continuous data feedback for pressure, temperature, flow, level, and other industrial parameters.
Signal Transmission Stability: Ensures accurate and low-interference transmission of analog signals to control systems.
Industrial Data Integration: Enables integration of field data into distributed control systems (DCS) for process automation.
Environmental Adaptability: Maintains reliable operation under harsh conditions such as vibration, shock, humidity, and airborne contaminants.
Installation and Wiring Efficiency: Uses standardized terminal design to simplify installation and improve wiring accuracy.
The KJ3223X1-EA1 12P2867X022 provides reliable monitoring and control support by accurately collecting analog signals from field instruments and transmitting them to control systems. It enables real-time monitoring of key process variables such as temperature, pressure, flow, and level.
The module ensures stable and low-noise signal acquisition across all 16 channels, allowing control systems to make accurate operational decisions. Its design minimizes interference and maintains signal integrity even in electrically noisy industrial environments.
With strong environmental resistance, the KJ3223X1-EA1 12P2867X022 operates reliably under vibration, shock, humidity, and airborne contaminants. This ensures continuous and accurate data acquisition for safe and efficient industrial process control.
Q1: What is the input power rating of the Emerson KJ3223X1-EA1 12P2867X022?
A1: The KJ3223X1-EA1 12P2867X022 supports 30 VDC input power at 100 mA.
Q2: Is the Emerson KJ3223X1-EA1 12P2867X022 suitable for harsh environments?
A2: Yes, the KJ3223X1-EA1 12P2867X022 is designed for harsh industrial environments with strong resistance to mechanical stress and contamination.
Q3: What is the weight of the Emerson KJ3223X1-EA1 12P2867X022?
A3: The KJ3223X1-EA1 12P2867X022 weighs approximately 0.1 kg.
Q4: What is the role of this module in process control systems?
A4: The KJ3223X1-EA1 12P2867X022 provides accurate analog signal input data to help control systems monitor and regulate industrial processes.
Q5: Why is the Emerson KJ3223X1-EA1 12P2867X022 important in automation systems?
A5: The KJ3223X1-EA1 12P2867X022 improves process visibility, data accuracy, and system reliability by providing stable multi-channel analog input acquisition for industrial automation.
