Product Name: Eddy Current Sensor
Brand Name: Emerson
Model Number: PR6423/13R-030 CON021
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Tag
| Non-contact Displacement Sensor | Predictive Maintenance Sensor |
| Emerson Epro Sensor | PLC Compatible Sensor |
| Shaft Vibration Monitoring | DCS Integrated Sensor |
| Rotating Machinery Monitoring | Emerson AMS Compatible |
| Turbine Condition Monitoring | High Precision Industrial Sensor |
| Compressor Monitoring Sensor | 4–20 mA Output Sensor |
| Pump Vibration Sensor | Dynamic Voltage Output Sensor |
| Shaft Position Measurement | High Temperature Industrial Sensor |
| Industrial Condition Monitoring | Anti-EMI Shielded Sensor |
| Factory Calibrated Measurement System |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Emerson PR6423/13R-030 CON021 Eddy Current Sensor |
| Manufacturer | Emerson |
| Product Type | Eddy Current Sensor |
| Part Number | PR6423/13R-030 CON021 |
| Weight | 0.54kg |
| Estimated shipping dimensions | 22x18x4cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Measurement Principle | Non-contact eddy current sensing |
| Probe Tip Diameter | 8 mm |
| Measurement Range | 0 to 2 mm (linear range depends on calibration target material) |
| Sensitivity | 8 mV/µm (typical value depending on system calibration) |
| Output Signal | 4–20 mA or dynamic voltage signal via CON021 |
| Frequency Response | DC to 10 kHz |
| Linearity Deviation | ≤ ±1% of full scale |
| Resolution | ≤ 0.5 µm |
| Repeatability | ≤ 0.2% of full scale |
| Cable Length | 3.0 m integrated coaxial cable |
| Total System Length | Probe + extension cable + driver matched system |
| Operating Temperature (Probe) | −35 °C to +180 °C |
| Operating Temperature (Converter) | −30 °C to +70 °C |
| Storage Temperature | −40 °C to +100 °C |
| Probe Material | Stainless steel housing |
| Cable Type | Shielded coaxial cable with high EMI resistance |
| Mounting Thread | M10 × 1 |
| Protection Class | IP65 (probe, when properly installed) |
| Power Supply | −24 VDC (via CON021 driver module) |
| Current Consumption | Typically < 50 mA |
| Weight | Approx. 0.3–0.5 kg (complete system) |
| Target Material | Conductive materials such as steel or alloy |
| Calibration | Factory calibrated system (probe + cable + driver matched) |
| Installation Distance | Defined initial gap required for accurate measurement |
| Signal Interface | Compatible with PLC, DCS, and Emerson AMS systems |
The Emerson PR6423/13R-030 CON021 Eddy Current Sensor is a high-precision non-contact displacement measurement system designed for rotating machinery monitoring applications. Utilizing advanced eddy current sensing technology, the system delivers accurate shaft displacement, vibration, and position monitoring for turbines, compressors, pumps, and other critical industrial equipment.
This Emerson Epro sensor system combines the PR6423 probe with the CON021 driver module to provide stable signal transmission, high reliability, and seamless integration with PLC, DCS, and Emerson AMS platforms. With excellent resistance to EMI and wide operating temperature capability, the sensor ensures dependable performance in harsh industrial environments and continuous operation conditions.
Factory-Calibrated System Setup
The PR6423/13R-030 and CON021 are delivered as a factory-calibrated matched system, meaning the probe, cable, and driver are pre-aligned to ensure accurate measurement performance without requiring field calibration of the sensing chain.
Power Supply Configuration
The CON021 driver module is powered by −24 VDC. Proper and stable power input is required to ensure correct sensor excitation, signal stability, and long-term operational reliability in industrial environments.
Signal Output Configuration
The system provides either a 4–20 mA process signal or a dynamic voltage output depending on the CON021 configuration. This allows flexible integration into both process control and condition monitoring systems.
PLC / DCS Integration Setup
The output signals can be directly connected to PLC or DCS systems for real-time monitoring of vibration, shaft displacement, and position data. Scaling and signal mapping are configured within the control system’s analog input modules.
Emerson AMS System Integration
When used with Emerson AMS platforms, the sensor can be configured for continuous asset monitoring, enabling diagnostic functions, trend analysis, and predictive maintenance workflows through standardized communication interfaces.
Installation Gap Configuration
A defined initial air gap between the probe tip and the conductive target surface must be set during installation. This gap is critical for ensuring linear response within the 0–2 mm measurement range.
Alarm and Threshold Programming
In monitoring systems, alarm thresholds (warning and danger limits) can be programmed based on displacement or vibration values, enabling automatic protection actions for turbines, compressors, and pumps.
