Honeywell CC-PAOX01 51405039-275 Analog Output with non-HART Original new

Honeywell CC-PAOX01 51405039-275 Analog Output with non-HART Original new

Product Name:Analog Output

Brand Name:Honeywell

Model Number:CC-PAOX01 51405039-275

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

honeywell cc paox01 51405039 275 analog output with non hart original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Honeywell
Model Number:	CC-PAOX01 51405039-275
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Description
Product Model	CC-PAOX01 51405039-275
Brand	Honeywell
Product Type	High-Level Analog Output Module
Output Signal Type	4–20 mA
Number of Output Channels	16 Channels
Output Ripple	<100 mV Peak-to-Peak
Output Linearity	±0.05% of Full Scale
Calibrated Accuracy	±0.35% of Full Scale
Maximum Resistive Load	800 Ohms
Maximum Output Voltage	16 V
Response Time	Within 80 ms
Redundancy Support	Optional
Open Wire Detection	Supported
Compatible IOTAs	CC-TAOX01, CC-TAOX11, CC-GAOX11, CC-GAOX21
Dimensions	5.5x16x14.5cm
Weight	0.4kg

Description

Honeywell CC-PAOX01 51405039-275 is a high-level analog output module engineered for precise current signal transmission in Experion Series C distributed control systems. Designed to deliver stable 4–20 mA output signals, the module is widely used for driving actuators, control valves, and industrial indicating devices in demanding process automation environments. Its advanced design ensures reliable performance and consistent output accuracy across continuous industrial operations.

The CC-PAOX01 51405039-275 supports comprehensive self-diagnostics, configurable FAILOPT safety functions, and optional redundant architecture for critical process applications. Compatible with CC-TAOX01, CC-TAOX11, CC-GAOX11, and CC-GAOX21 IOTA assemblies, the module provides flexible installation options for both standard and hazardous-area industrial systems.

With integrated open-wire detection, output validation capability, and low output ripple performance, the Honeywell CC-PAOX01 improves system reliability, operational safety, and signal integrity in power generation, chemical processing, oil & gas, and manufacturing automation industries.

Applications

Power plants: Used for turbine valve control, actuator signal output, and process regulation systems.
Substations: Supports analog signal transmission for switchyard automation and monitoring systems.
Chemical plants: Integrates with distributed control systems for accurate process output management.
Oil & gas facilities: Provides stable analog control signals for field instrumentation and control valves.
Steel mills: Performs reliable output control in high-temperature and electromagnetic interference environments.
Water treatment plants: Used for pump speed regulation and automated dosing system control.
Machinery manufacturing plants: Supports robotic systems, conveyor automation, and industrial production equipment.

Features

High-level 4–20 mA analog output module
16-channel industrial output design
Advanced self-diagnostic capability
Configurable FAILOPT safety behavior
Optional redundant architecture support
Open-wire fault detection function
Stable low-ripple output performance
High signal accuracy and linearity
Supports industrial hazardous-area applications
Compatible with multiple Honeywell Series C IOTAs

Functions

Delivers accurate analog current output signals
Controls industrial actuators and valves
Supports process automation output regulation
Detects field wiring failures automatically
Provides signal validation and readback monitoring
Maintains stable output during continuous operation
Supports safe-state output protection functions
Enhances distributed control system reliability

FAQ

Q1: What is the main function of CC-PAOX01 51405039-275?
A1: It provides precise 4–20 mA analog output signals for industrial actuators and control devices.

Q2: How many output channels does the CC-PAOX01 support?
A2: The module supports 16 independent analog output channels.

Q3: Does the CC-PAOX01 51405039-275 support redundancy?
A3: Yes, optional redundancy is available for critical process control applications.

Q4: Which IOTA assemblies are compatible with this module?
A4: It is compatible with CC-TAOX01, CC-TAOX11, CC-GAOX11, and CC-GAOX21.

Q5: What industries commonly use the CC-PAOX01 module?
A5: It is widely used in power generation, chemical processing, oil & gas, water treatment, and manufacturing industries.
