Product Name: 16mm Eddy Current Sensor
Brand Name: EMERSON
Model Number: PR6424/000-040 CON021
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Tag
| Non-Contact Displacement Sensor | Compressor Monitoring System |
| Vibration Monitoring Sensor | Generator Condition Monitoring |
| Shaft Position Monitoring | Industrial Automation Sensor |
| Industrial Condition Monitoring | Real-Time Vibration Detection |
| Emerson EPRO Sensor | Stainless Steel Sensor |
| Rotating Machinery Protection | PTFE Cable Sensor |
| Predictive Maintenance Sensor | Harsh Environment Sensor |
| High-Precision Measurement Sensor | Shaft Displacement Measurement |
| DCS Compatible Sensor | Industrial Diagnostic Sensor |
| Turbine Monitoring Sensor |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | EMERSON PR6424/000-040 CON021 Eddy Current Sensor |
| Manufacturer | EMERSON |
| Product Type | Eddy Current Sensor |
| Part Number | PR6424/000-040 CON021 |
| Estimated shipping dimensions | 16x16x4cm |
| Weight | 0.4 kg |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Sensitivity/Linearity | 4 V/mm (101.6 mV/mil) ≤ ±1.5% |
| Air Gap (Center) | Approx. 2.7 mm (0.11”) Nominal |
| Long Term Drift | < 0.3% |
| Range Static | ±2.0 mm (0.079”) |
| Dynamic | 0 to 1,000μm (0 to 0.039”) |
| Maximum Surface Speed | 2,500 m/s (98,425 ips) |
| Shaft Diameter | ≥80mm |
| Operating Temperature Range | -35 to 150°C (-31 to 302°F) |
| Material Sleeve | – Stainless Steel, Cable – PTFE |
The Emerson PR6424/000-040 CON021 Eddy Current Sensor is a high-precision non-contact measurement device designed for monitoring shaft displacement, vibration, and position in rotating industrial machinery. Using advanced eddy current technology, it provides stable and accurate real-time data for machinery condition monitoring and predictive maintenance applications.
Engineered for harsh industrial environments, the sensor features stainless steel and PTFE construction, ensuring long-term durability under high temperatures, vibration, and corrosive conditions. It is widely used in turbines, compressors, generators, and other critical rotating equipment where high reliability and measurement accuracy are essential.
System Configuration
The PR6424/000-040 CON021 sensor is designed for seamless integration into Distributed Control Systems (DCS), machinery protection systems, and industrial condition monitoring platforms. It is widely deployed in rotating equipment such as turbines, compressors, and generators to provide continuous real-time vibration and displacement monitoring for predictive maintenance applications.
Measurement Configuration
The sensor supports a static measurement range of ±2.0 mm and a dynamic range of 0 to 1000 µm, enabling precise tracking of shaft displacement and vibration behavior. Its nominal air gap of 2.7 mm ensures stable installation alignment and consistent measurement accuracy in high-speed rotating machinery.
Signal Processing Configuration
With a sensitivity of 4 V/mm and linearity error within ≤ ±1.5%, the sensor delivers accurate and stable signal output for industrial diagnostics. Long-term drift below 0.3% further enhances measurement stability, ensuring reliable performance during continuous operation.
Electrical Configuration
The sensor is optimized for industrial signal acquisition systems, providing a stable output compatible with monitoring and control units. Its design ensures consistent signal transmission for real-time data processing in automation environments.
Environmental & Mechanical Configuration
Built with stainless steel and PTFE materials, the sensor is engineered for harsh industrial environments. It operates reliably across a wide temperature range from -35°C to +150°C and supports high surface speeds up to 2,500 m/s, making it suitable for demanding rotating machinery applications.
