GE 90-30 Series PLC

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Product Parameters

Product Name	GE HE693RTD600 INPUT MODULE
Manufacturer	General Electric
Product Type	INPUT MODULE
Part Number	HE693RTD600
Weight	0.28 kg
Estimated shipping dimensions	3.5x13x13.5cm
Place of shipment	Xiamen, China
Country of origin	USA
Number of Channels	6
I/O Points Required	6% AI
Input Impedance	>1000 Meg W
Fault Protection	Zener Diode Clamp
A/D Conversion Type	16 bit, Integrating
Update Time	50 Channels per second
Channel to ChannelTracking	0.1°C
Resolution	0.5°C or 0.5°F
Accuracy	± 0.5°C typical,± 1.0°C for Cu-10 andTD5R
Operating Temperature	0 to 60°C (32° to 140°F)

Introduction

The GE HE693RTD600 is a high-performance RTD (Resistance Temperature Device) Input Module designed for accurate temperature measurement and monitoring in industrial automation systems. Manufactured by Horner Electric and compatible with PLC I/O applications, this module supports up to six RTD input channels, allowing multiple temperature sensing points to be monitored simultaneously. Its advanced signal processing capabilities ensure precise temperature acquisition for process control, equipment monitoring, and industrial safety applications.

The HE693RTD600 utilizes a 16-bit integrating A/D conversion system to deliver reliable and accurate temperature measurements with a resolution of 0.5°C or 0.5°F. With a fast update rate of up to 50 channels per second, high input impedance, and built-in fault protection through a Zener diode clamp, the module provides dependable performance in demanding industrial environments. Its compact design, excellent channel tracking capability, and broad compatibility make it an ideal solution for manufacturing, energy, water treatment, and process automation applications.

Functions

Collects temperature signals from RTD sensors across multiple channels
Converts analog temperature signals into digital data for PLC processing
Supports simultaneous monitoring of up to six temperature points
Provides high-resolution temperature measurement for industrial control
Ensures stable data acquisition through integrating A/D conversion
Maintains accurate multi-channel tracking for consistent readings
Protects input circuits against electrical faults using internal safeguards
Delivers real-time temperature data for process optimization
Supports integration with PLC and industrial automation systems
Enhances operational visibility in temperature-critical applications

Features

Six-channel RTD input module for multi-point temperature monitoring
16-bit integrating analog-to-digital conversion for stable measurement
Resolution of 0.5°C / 0.5°F for precise temperature reading
Update speed up to 50 channels per second for fast data acquisition
Channel-to-channel tracking accuracy of 0.1°C for consistency
Input impedance greater than 1000 MΩ to minimize sensor loading effects
Typical accuracy of ±0.5°C for standard RTD inputs
Accuracy of ±1.0°C for Cu-10 and TD5R sensor types
Zener diode clamp protection for input fault safety
Low power consumption design at 75 mA @ 5 VDC
Expandable system support via memory and Fieldbus options
Compact industrial-grade construction for PLC integration
Operating temperature range from 0°C to 60°C
High reliability for continuous industrial operation
Designed for harsh industrial automation environments

Advantage

Compared with similar RTD input modules, the HE693RTD600 provides higher measurement precision, faster data refresh, stronger signal integrity, and more stable multi-channel temperature monitoring performance.

High Measurement Precision
The HE693RTD600 delivers accurate temperature readings with a typical precision of ±0.5°C using 16-bit integrating A/D conversion. This ensures better process control compared with lower-resolution RTD modules.

Fast Data Refresh Rate
With the ability to update up to 50 channels per second, the HE693RTD600 provides rapid temperature feedback, enabling timely response in dynamic industrial processes.

Excellent Multi-Channel Consistency
The module ensures channel-to-channel tracking accuracy of 0.1°C, providing highly consistent readings across all six input channels, which is essential for comparative temperature monitoring.

Strong Electrical Protection
Built-in Zener diode clamp protection enhances resistance against electrical faults and transient voltage conditions, improving long-term operational reliability and system safety.

High Signal Integrity Design
With input impedance exceeding 1000 MΩ, the HE693RTD600 minimizes sensor loading effects and ensures stable, distortion-free temperature measurements in industrial environments.

FAQ

How many input channels does the HE693RTD600 support?

The HE693RTD600 supports six independent RTD input channels, allowing multiple temperature measurement points to be monitored simultaneously.

What level of measurement accuracy does the HE693RTD600 provide?

The HE693RTD600 offers a typical measurement accuracy of ±0.5°C, while accuracy for Cu-10 and TD5R sensors is ±1.0°C.

What is the resolution of the HE693RTD600?

The HE693RTD600 provides a temperature resolution of 0.5°C or 0.5°F, enabling precise temperature monitoring and control.

How fast can the HE693RTD600 update measurement data?

The HE693RTD600 supports an update rate of up to 50 channels per second, ensuring timely acquisition of temperature information in fast-moving industrial processes.

What type of A/D conversion is used in the HE693RTD600?

The HE693RTD600 utilizes 16-bit integrating A/D conversion technology to provide accurate and stable temperature measurements.
