Product Name: Analog Output Module
Brand Name: General Electric
Model Number: IC693ALG391
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The GE IC693ALG391 is an Analog Output Module designed for the GE Fanuc Series 90-30 PLC platform. It provides precise analog signal output for controlling field devices such as variable frequency drives, control valves, actuators, recorders, and process instruments. The module converts digital control data from the PLC into accurate voltage or current output signals, enabling reliable control of industrial processes.
The IC693ALG391 supports both current and voltage output ranges, including 0–20 mA, 4–20 mA, 0–5 V, and 1–5 V signals. Factory calibrated for high accuracy, the module delivers stable analog performance and flexible integration into process control systems. Its compatibility with both backplane and external power sources makes it suitable for a wide variety of industrial automation applications.
| Product Name | GE IC693ALG391 Analog Output Module |
| Manufacturer | General Electric |
| Product Type | Analog Output Module |
| Part Number | IC693ALG391 |
| Weight | 0.34kg |
| Estimated shipping dimensions | 3.5x13x13.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Output Current Range | 4 to 20 mA and 0 to 20 mA |
| Output Voltage Range | 1 to 5 V and 0 to 5 V |
| Calibration | Factory calibrated to 4µA per count |
| Supply Voltage | +24 VDC, from isolated +24 VDC on backplaneor user supplied voltage source, and +5 VDC frombackplane |
| External Supply Voltage Range | 20 to 30 VDC |
| 4 to 20 mA | 4µA |
| 0 to 20 mA | 5µA |
| 1 to 5 V | 1 mV |
| 0 to 5 V | 1.25 mV |
| Maximum Compliance Voltage | 25 V |
| User Load | 0 to 850 ohms |
Multi-range output support: provides both voltage and current outputs within a single module
High output accuracy: factory calibration ensures reliable and precise analog signal generation
Flexible installation: supports both external and backplane power sources
Broad application compatibility: suitable for process control, motion control, and instrumentation systems
Strong load support: accommodates user loads up to 850 ohms for current-loop applications
Compared with similar products: offers greater output flexibility and calibration accuracy than many single-range analog output modules
Reduced system complexity: one module can support multiple analog signal standards, reducing hardware requirements
Compared with similar analog output modules, the IC693ALG391 delivers greater signal flexibility, high calibration accuracy, and versatile power options, making it an efficient solution for industrial process control and automation systems.
The IC693ALG391 is fully compatible with GE Fanuc Series 90-30 PLC systems and integrates directly into the PLC backplane architecture. It works seamlessly with Series 90-30 CPUs, communication modules, and I/O systems, providing reliable analog signal generation within the automation platform.
The module interoperates with a wide range of industrial devices that utilize standard voltage and current control signals, including control valves, variable frequency drives, actuators, transmitters, and process controllers. Its support for common industrial analog signal standards ensures smooth integration into both new and existing automation and process control systems.
