Product Name: Single-Slot CPU Module
Brand Name: GE
Model Number: IC693CPU364
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | GE IC693CPU364 Single-Slot CPU Module |
| Manufacturer | GE |
| Product Type | Single-Slot CPU Module |
| Part Number | IC693CPU364 |
| Weight | 0.34kg |
| Estimated shipping dimensions | 3.5x13x13.7cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Processor Speed | 25 MegaHertz |
| Processor Type | 80386EX |
| Discrete Input Points | - %I 2,048 |
| Discrete Output Points | - %Q 2,048 |
| Discrete Global Memory | - %G 1,280 bits |
| Internal Coils | - %M 4,096 bits |
| CPU Type | Single slot CPU module with embedded Ethernet Interface |
| Output (Temporary) Coils | - %T 256 bits |
The GE Fanuc IC693CPU364 is a high-performance single-slot CPU module designed for the Series 90-30 PLC system. It serves as the central processing unit of the control rack, executing logic instructions and managing all system operations across connected I/O modules and expansion baseplates. Built on an 80386EX processor operating at 25 MHz, the CPU provides reliable and deterministic control performance for medium to large-scale industrial automation applications.
Equipped with an embedded Ethernet interface, the IC693CPU364 enables efficient communication between PLC systems, supervisory control systems, and industrial networks. With support for up to 8 baseplates (1 CPU baseplate and 7 expansion/remote baseplates), it provides scalable architecture for distributed control applications. Its robust memory structure and high I/O capacity make it suitable for complex process control environments requiring stable and continuous operation.
The IC693CPU364 functions as the core logic execution and system coordination unit within the Series 90-30 PLC architecture. It continuously processes control programs, executing Boolean logic at a typical scan rate of 0.22 milliseconds per 1K contacts. Through the rack backplane, it distributes control commands to I/O modules, ensuring real-time response and synchronization across all connected devices.
In addition to logic execution, the CPU manages extensive system memory, including discrete inputs (%I), outputs (%Q), internal coils (%M), global memory (%G), and temporary coils (%T). It also handles register-based data processing, shift registers, timers, counters, and system registers (%SR), enabling advanced control strategies and data handling. The embedded Ethernet interface further supports communication, diagnostics, and data exchange with higher-level systems, ensuring full integration into industrial automation networks.
The GE Fanuc IC693CPU364 is designed for integration within the Series 90-30 PLC ecosystem and is compatible with:
Its combination of high-speed processing, extensive memory resources, scalable architecture, and embedded Ethernet communication makes the IC693CPU364 a powerful and reliable CPU solution for complex industrial control applications.
