Product Name: Positive/Negative Logic Input Module
Brand Name: GE
Model Number: IC693MDL646
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | GE IC693MDL646 Positive/Negative Logic Input Module |
| Manufacturer | GE |
| Product Type | Positive/Negative Logic Input Module |
| Part Number | IC693MDL646 |
| Weight | 0.28kg |
| Estimated shipping dimensions | 3.5x13x13.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Rated Voltage | 24 volts DC |
| Input Voltage Range | 0 to +30 volts DC |
| Inputs per Module | 16 (one group with a single common) |
| Isolation | 1500 volts between field side and logic side |
| Input Current | 7 mA (typical) at rated voltage |
| On-state Voltage | 11.5 to 30 volts DC |
| Off-state Voltage | 0 to +5 volts DC |
| On-state Current | 3.2 mA minimum |
| Off-state Current | 1.1 mA maximum |
| Off/On response Time | 1 ms typical |
| Power Consumption 5V | 80 mA (all inputs on) from 5 volt bus on backplane |
| Power Consumption 24V | 125 mA from the Isolated 24 volt backplane bus or from user supplied power |
The GE Fanuc IC693MDL646 Positive/Negative Logic Input Module is a high-speed digital input module designed for the Series 90-30 PLC system. It provides 16 input channels in a single group with a common terminal, enabling efficient acquisition of field signals from industrial devices such as pushbuttons, limit switches, and proximity sensors. With support for both positive and negative logic configurations, the module offers flexible integration across a wide range of control system designs.
Manufactured by General Electric, the IC693MDL646 is engineered for reliable operation in demanding industrial environments where fast and accurate signal detection is required. Operating at 24 V DC with an input range up to 30 V DC, the module delivers stable performance with a typical response time of 1 ms. Its robust design and electrical isolation make it suitable for critical automation and process control applications within GE Series 90-30 PLC architectures.
The IC693MDL646 functions as a digital signal acquisition interface between field devices and the PLC system. It continuously monitors up to 16 input points, detecting ON/OFF states of connected devices and converting them into logic signals for processing by the CPU. This enables real-time monitoring of machine status, process conditions, alarms, and control signals within industrial automation systems.
In addition to signal detection, the module supports both sourcing (positive logic) and sinking (negative logic) configurations, allowing compatibility with diverse field wiring schemes. It provides fast input response with a typical 1 ms switching time, ensuring accurate capture of high-speed events. The 1500 V isolation between field and logic sides enhances operational safety and minimizes electrical noise interference, ensuring stable and reliable system performance.
The GE IC693MDL646 is designed for integration within the GE Series 90-30 PLC ecosystem and is compatible with:
Its combination of fast response time, dual-logic flexibility, strong electrical isolation, and compact 16-channel design makes the IC693MDL646 a reliable and versatile input solution for high-performance industrial automation systems.
