Product Name: Universal Analog Input Module
Brand Name: General Electric
Model Number: IC695ALG600
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The GE IC695ALG600 is a Universal Analog Input Module designed for the GE PACSystems RX3i platform. It provides highly flexible analog signal acquisition by supporting a wide variety of input types, including voltage, current, thermocouple, RTD, and resistance signals. This versatility allows a single module to accommodate multiple measurement requirements, reducing system complexity and inventory costs in industrial automation applications.
Engineered for demanding process and manufacturing environments, the IC695ALG600 delivers accurate signal conversion and configurable filtering options to optimize measurement quality. Its broad input compatibility makes it suitable for temperature monitoring, process control, equipment diagnostics, and data acquisition systems where multiple sensor technologies are used within the same control architecture.
| Product Name | GE IC695ALG600 Universal Analog Input Module |
| Manufacturer | General Electric |
| Product Type | Universal Analog Input Module |
| Part Number | IC695ALG600 |
| Weight | 0.18 kg |
| Estimated shipping dimensions | 3.5x13.5x13.6cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Resistance Inputs | 0 to 250 / 500 / 1000 / 2000 / 3000 / 4000 ohms |
| Input signals, Current | 0-20 mA; 4-20 mA; +/-20 mA |
| RTD Inputs | PT 385 / 3916, N 618 / 672, NiFe 518, CU 426 |
| Input signals, Voltage | +/- 50 mV; +/- 150 mV; +/-10VDC; 0-10 VDC; +/-5VDC; 0-5 VDC and 1 - 5 VDC |
| Configurable Input Filter | 8 Hz, 12 Hz, 16 Hz, 40 Hz, 200 Hz, 1000 Hz |
| RTD inputs | PT 385 / 3916, N 618 / 672, NiFe 518, CU 426 |
| Thermocouple inputs | B, C, E, J, K, N, R, S, T |
| Operating Temperature | 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit) |
| Storage Temperature | -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit) |
Universal input capability: supports voltage, current, thermocouple, RTD, and resistance inputs in a single module
Reduced hardware requirements: eliminates the need for multiple dedicated analog input modules
Broad sensor compatibility: accommodates a wide range of industrial sensors and instruments
Configurable filtering: selectable filter settings improve signal stability in noisy environments
Enhanced application flexibility: suitable for process, manufacturing, and monitoring applications with diverse signal types
Compared with similar products: offers greater input versatility and sensor compatibility than standard analog input modules that support only voltage or current signals
Lower lifecycle costs: simplifies spare parts management by replacing multiple specialized modules with one universal solution
Compared with similar analog input modules, the IC695ALG600 provides superior flexibility, broader sensor support, configurable filtering, and reduced system complexity, making it an ideal choice for advanced industrial automation and process control applications.
The IC695ALG600 is fully compatible with the GE PACSystems RX3i platform and integrates seamlessly with RX3i CPUs, backplanes, communication modules, and other I/O modules. Its universal input architecture allows multiple signal types to be processed within the same control system, simplifying system design and expansion.
The module interoperates with a broad range of industrial instruments, including transmitters, thermocouples, RTDs, resistance-based sensors, and analog process devices. Its support for industry-standard signal ranges enables smooth integration into existing automation systems, process control networks, and data acquisition applications without requiring specialized interface equipment.
