Product Name:Resistance Temperature Module
Brand Name: SIEMENS
Model Number:39RTMCAN
Country of Origin:GERMANY
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
SIEMENS |
Model Number: |
39RTMCAN |
Country of Origin: |
GERMANY |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Specification |
Details |
|
Model Number |
39RTMCAN |
|
Alternate Part Numbers |
16207-61/10, 16207-61/11, 16207-61/13 |
|
Product Type |
Resistance Temperature Module (RTM) |
|
System Compatibility |
Siemens APACS+, QUADLOG |
|
Number of Channels |
16 configurable channels (isolated into 8 groups of 2 channels each) |
|
Supported Sensor Types |
PT100, PT1000, NI100 RTDs and other resistive temperature detectors |
|
Wiring Configurations |
2-wire, 3-wire, or 4-wire RTD connections |
|
Measurement Range |
-200°C to +850°C |
|
Accuracy |
±0.1% of reading + 1°C (typical); ±0.1°C to ±0.5°C depending on sensor |
|
Resolution |
0.01°C |
|
Response Time |
≤0.5 seconds (95% change); ≤5 seconds typical |
|
Operating Temperature |
-25°C to +70°C (module); -40°C to +125°C (sensing) |
|
Storage Temperature |
-40°C to +85°C |
|
Operating Voltage |
24V DC (12V to 30V DC range) |
|
Power Consumption |
≤10mA operating current; ≤5mW typical |
|
Protection Rating |
IP20 (module); IP65 / IP67 (sensor variant) |
|
Dimensions (HxWxD) |
7.6 cm x 27.9 cm x 35.6 cm (rack-mount chassis) |
|
Weight |
Approximately 1.8 kg to 1.9 kg |
|
Certifications |
CE, UL, CSA |
|
LED Indicators |
Module health and channel status diagnostics |
The Siemens 39RTMCAN Resistance Temperature Module (RTM) is engineered for the APACS+ process control system and QUADLOG safety controller. The Siemens 39RTMCAN interfaces directly with Resistance Temperature Detectors (RTDs) such as PT100 sensors, converting resistance signals into accurate digital temperature data via the IOBUS backplane. Featuring 16 configurable channels, this RTM module provides electrical isolation between input channels and the control CPU. The Siemens 39RTMCAN delivers a fast response time under 0.5 seconds with typical accuracy of ±0.1% of reading, ensuring reliable temperature monitoring for demanding industrial automation applications and legacy system expansions.
Chemical and Petrochemical Process Control
Oil & Gas Refineries
Power Generation Plants
Pharmaceutical Manufacturing
Food & Beverage Processing
HVAC Systems and Building Automation
Industrial Machinery Temperature Monitoring
Legacy APACS+ System Maintenance and Expansion
16 configurable input channels with support for RTD sensors (PT100, PT1000, NI100, etc.)
High-precision measurement with accuracy of ±0.1% of reading + 1°C
Supports 2‑wire, 3‑wire, or 4‑wire RTD configurations
Fast response time under 0.5 seconds for 95% signal change
Electrical isolation between each channel group, CPU, IOBUS, and ground
Wide operating temperature range of -25°C to +70°C
LED indicators for real‑time module diagnostics
CE, UL, and CSA certified
Robust construction for demanding industrial environments
Long‑term availability for APACS+ system support
Interfaces RTD and other resistance input signals to the APACS+ controller’s IOBUS
Converts resistance changes from temperature sensors into linearized digital temperature values
Provides electrical isolation between input circuits, the module’s CPU, IOBUS, and ground
Supports three‑wire and four‑wire RTD configurations to automatically compensate for wire resistance errors
Enables simultaneous temperature monitoring across 16 channels in eight isolated groups
Delivers real‑time temperature data for process control loops and safety systems
Facilitates seamless integration into both APACS+ and QUADLOG automation architectures
Q1: Is the Siemens 39RTMCAN compatible with my existing APACS+ system?
A1: Yes. The Siemens 39RTMCAN is fully compatible with APACS+ process control systems and QUADLOG safety controllers, making it ideal for legacy system expansions and maintenance.
Q2: What RTD sensors does the 39RTMCAN support?
A2: The Siemens 39RTMCAN supports a wide range of RTD sensors including PT100, PT1000, NI100, and other resistive temperature detectors that follow standard calibration curves.
Q3: How many input channels does the Siemens 39RTMCAN provide?
A3: The Siemens 39RTMCAN provides 16 configurable input channels isolated into eight groups of two channels each, supporting simultaneous temperature monitoring from multiple sensors.
Q4: Does the 39RTMCAN support 3-wire RTD configurations?
A4: Yes. The 39RTMCAN supports 2‑wire, 3‑wire, and 4‑wire RTD configurations, with 3‑wire and 4‑wire setups minimizing errors due to lead wire resistance for more accurate temperature readings.
Q5: What is the typical accuracy of the Siemens 39RTMCAN RTM?
A5: The Siemens 39RTMCAN typically achieves an accuracy of ±0.1% of reading plus 1°C, or within a ±0.1°C to ±0.5°C range depending on the RTD sensor used and environmental conditions.
