Product Name: Ethernet Interface Module
Brand Name: General Electric
Model Number: IC695ETM001
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The GE IC695ETM001 is an Ethernet Interface Module designed for the GE PACSystems RX3i automation platform. It provides high-speed Ethernet connectivity for industrial control systems, enabling communication between PLCs, HMIs, SCADA systems, engineering workstations, and other networked devices. The module supports both 10 Mbps and 100 Mbps Ethernet networks, making it suitable for a wide range of industrial communication applications.
Equipped with a 200 MHz Ethernet processor, dual auto-sensing RJ-45 Ethernet ports, and an integrated Ethernet switch, the IC695ETM001 simplifies network architecture while delivering reliable data exchange. It also includes an RS-232 Station Manager port for configuration and diagnostics, providing flexibility for system setup, maintenance, and troubleshooting in demanding industrial environments.
| Product Name | GE IC695ETM001 Ethernet Interface Module |
| Manufacturer | General Electric |
| Product Type | Ethernet Interface Module |
| Part Number | IC695ETM001 |
| Weight | 0.35 kg |
| Estimated shipping dimensions | 3.4x14x14.1cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Ethernet processor speed | 200 MHz |
| Connectors | Station Manager (RS-232) Port: 9-pin female D-connector, Two 10BaseT / 100BaseTX Ports: 8-pin female shielded RJ-45. |
| LAN | IEEE 802.2 Logical Link Control Class I , IEEE 802.3 CSMA/CD Medium Access Control 10/100 Mbps. |
| Number of IP addresses | One |
| Number of Ethernet Port Connectors | Two, both are 10BaseT / 100BaseTX with auto-sensing RJ-45 connection. |
| Embedded Ethernet Switch | Yes – Allows daisy chaining of Ethernet nodes. |
| Serial Port | Station Manager Port: RS-232 DCE, 1200 - 115200 bps. |
Integrated Ethernet switch: eliminates the need for additional external switches in many applications
Dual Ethernet ports: simplifies network expansion and supports daisy-chain topologies
High-speed processing: 200 MHz Ethernet processor ensures efficient communication handling
Flexible connectivity: supports both 10 Mbps and 100 Mbps Ethernet networks
Simplified installation: auto-sensing ports automatically adapt to network speed requirements
Compared with similar products: offers built-in switching capability and dual-port connectivity that reduce network complexity and installation costs
Enhanced maintenance support: dedicated RS-232 Station Manager port simplifies configuration and troubleshooting
Compared with similar Ethernet interface modules, the IC695ETM001 delivers greater networking flexibility, simplified system architecture, faster communication processing, and reduced infrastructure costs through its integrated Ethernet switch and dual-port design.
The IC695ETM001 is fully compatible with the GE PACSystems RX3i platform and integrates seamlessly with RX3i CPUs, I/O modules, and communication infrastructure. It supports Ethernet-based communication across automation systems, allowing efficient interaction between controllers and network-connected devices within the RX3i environment.
The module interoperates with industry-standard Ethernet networks and a wide range of automation equipment, including HMIs, SCADA systems, engineering workstations, data historians, and industrial servers. Its compliance with IEEE 802.2 and IEEE 802.3 standards ensures smooth integration into existing industrial Ethernet architectures, while the embedded switch enables straightforward expansion of distributed automation networks.
