GE IC697CHS750 REAR MOUNTING PLC RACK

Product Name: REAR MOUNTING PLC RACK

Brand Name: General Electric

Model Number: IC697CHS750

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Commercial Terms
Description
Functions
Parameter
Advantage
Performance & Efficiency
Compatibility & Interoperability
Recommended Products

Contact Us

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The GE IC697CHS750 Rear Mounting PLC Rack is a compact and reliable 5-slot I/O rack designed for the GE IC697 Series 90-70 PLC platform. Engineered for industrial automation applications, it provides a secure mounting structure for PLC modules, power supplies, and other system components. The rack features a rear-mount design that fits within a 10-inch (254 mm) deep enclosure, making it suitable for space-conscious control panel installations while maintaining easy access for maintenance and expansion.

Built with an open enclosure architecture, the IC697CHS750 utilizes natural convection cooling to dissipate heat efficiently without requiring additional fans under normal operating conditions. It supports both AC and DC plug-in power supplies and can be configured for dual-rack operation from a single power source, offering flexibility and scalability for a wide range of industrial control systems.

Functions

Supports all GE IC697 PLC module types within the Series 90-70 platform.
Provides five slots for installing I/O, CPU, communication, and specialty modules.
Enables secure rear-panel mounting in industrial control cabinets.
Accepts plug-in AC or DC IC697 power supplies.
Supports two-rack configurations powered by a single power supply.
Facilitates reliable backplane communication between installed modules.
Promotes efficient heat dissipation through convection cooling.
Simplifies system expansion and maintenance with modular rack architecture.
Provides stable mechanical support for PLC components in industrial environments.

Parameter

Product Name	GE IC697CHS750 REAR MOUNTING PLC RACK
Manufacturer	General Electric
Product Type	REAR MOUNTING PLC RACK
Part Number	IC697CHS750
Weight	3.5kg
Estimated shipping dimensions	32x18.5x26.7cm
Place of shipment	Xiamen, China
Country of origin	USA
Cooling	Convection cooling
Enclosure	Open Enclosure
Compatibility	IC697 PLC series
Description	Rear mount I/O rack
Rack enclosure	254 millimeters deep

Advantage

Universal IC697 Module Compatibility: Supports all GE IC697 Series 90-70 PLC modules, enabling flexible system configuration and seamless integration of CPUs, I/O, communication, and specialty modules.

Dual-Rack Power Capability: Allows two racks to operate from a single power supply, reducing hardware costs and simplifying overall system design.

Flexible AC/DC Power Supply Support: Compatible with both AC and DC IC697 plug-in power supplies, providing greater installation flexibility across various industrial environments.

Fan-Free Convection Cooling: Uses natural airflow for efficient heat dissipation, minimizing maintenance requirements, energy consumption, and cooling-related failures.

Compact Rear-Mount Design: Fits within a 10-inch (254 mm) deep enclosure, helping optimize control cabinet space without compromising accessibility.

Reliable Industrial Construction: Designed for long-term operation in demanding industrial applications, ensuring stable module connectivity and dependable system performance.

Compared with other PLC racks offering similar functionality, the GE IC697CHS750 delivers superior flexibility and cost efficiency through its full IC697 module compatibility, dual-rack power capability, and support for both AC and DC power supplies. Its fan-free cooling design reduces maintenance costs while improving reliability, and its compact rear-mount structure maximizes enclosure space utilization. These features make it a highly dependable and scalable solution for industrial automation systems.

Performance & Efficiency

Ensures reliable and stable data communication between installed PLC modules through its high-integrity backplane architecture.
Supports efficient power distribution across all rack slots, helping maintain consistent system performance.
Utilizes natural convection cooling, eliminating the need for cooling fans under normal operating conditions and reducing maintenance requirements.
Optimizes enclosure space with its compact rear-mount design, enabling efficient control panel layouts.
Enhances system uptime through robust mechanical construction and dependable module connectivity.
Reduces operating costs by minimizing additional cooling equipment and energy consumption.
Facilitates quick module installation and replacement, improving maintenance efficiency and reducing downtime.

Compatibility & Interoperability

The GE IC697CHS750 Rear Mounting PLC Rack is specifically designed for seamless integration with the GE IC697 Series 90-70 PLC platform. It supports the full range of IC697 CPU, I/O, communication, and specialty modules, allowing users to configure control systems according to specific application requirements. The rack also accommodates both AC and DC IC697 plug-in power supplies, providing flexibility for different industrial environments.

Its standardized backplane architecture ensures reliable interoperability among installed modules and supports expansion through multi-rack configurations. The capability to operate two racks from a single power supply simplifies system design and reduces hardware requirements. This high level of compatibility makes the IC697CHS750 an ideal solution for system upgrades, expansions, and maintenance within existing GE Fanuc automation infrastructures.
