Product Name: 9 SLOTS RACK
Brand Name: General Electric
Model Number: IC697CHS790
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The GE IC697CHS790 is a 9-slot programmable controller mounting rack designed for the GE Fanuc Series 90-70 PLC platform. It serves as the physical and electrical foundation for installing CPUs, I/O modules, communication modules, and other system components within a centralized automation architecture. Built for industrial control environments, the rack provides reliable module mounting, power distribution, and backplane communication support for medium- to large-scale automation systems.
The IC697CHS790 supports both front and rear mounting configurations, offering installation flexibility for different control cabinet layouts. With user-configurable I/O references and rack identification jumpers, it simplifies system configuration while eliminating the need for module jumpers or DIP switches. Its rugged design ensures dependable operation in demanding industrial applications requiring scalable and organized PLC installations.
| Product Name | GE IC697CHS790 9 SLOTS RACK |
| Manufacturer | General Electric |
| Product Type | 9 SLOTS RACK |
| Part Number | IC697CHS790 |
| Weight | 5.34kg |
| Estimated shipping dimensions | 48.3x28.3x18.6cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Supported mounting | Rear and Front mounting |
| Description | Programmable controller mounting rack |
| I/O References | User configurable without the use of module jumpers or DIP switches |
| Rack Identification | Four (4) jumpers behind rack power supply |
| Number of Slots | 5 or 9, plus power supply slot |
| Current Required from I/O Bus | 0.5 amps |
| Register memory | 240 kilobytes |
| Power requirements | 7.4 Watts at 5 Volts DC |
| Voltage | 5 Volts DC |
Flexible installation options: supports both front and rear mounting configurations for easier panel design
Simplified configuration: user-configurable I/O references eliminate the need for manual jumper or DIP switch settings
Efficient rack capacity: nine available slots accommodate a wide range of automation modules
Reliable system organization: centralizes module installation and communication within a single rack
Scalable architecture: supports system growth through modular expansion capabilities
Compared with similar products: offers greater configuration flexibility and easier installation than traditional PLC racks requiring extensive hardware addressing settings
Industrial-grade construction: designed for dependable operation in demanding automation environments
Compared with similar PLC mounting racks, the IC697CHS790 provides easier configuration, flexible mounting options, efficient module capacity, and simplified system expansion, making it a reliable platform for Series 90-70 automation systems.
The IC697CHS790 is fully compatible with GE Fanuc Series 90-70 PLC systems and supports the installation of compatible CPU, I/O, communication, and specialty modules. Its standardized rack architecture ensures seamless integration within existing Series 90-70 control systems while supporting future expansion requirements.
The rack interoperates with a wide range of Series 90-70 components through the integrated backplane communication structure. Its configurable I/O reference capabilities and rack identification features allow smooth integration into multi-rack PLC systems, enabling coordinated operation across complex industrial automation applications.
