Product Name: Communications Module
Brand Name: General Electric
Model Number: IC697CMM742
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The GE IC697CMM742 is a communications module designed for the GE Fanuc Series 90-70 PLC platform, providing Ethernet-based networking capabilities for industrial automation systems. It enables reliable communication between PLCs, computers, HMIs, SCADA systems, and other networked devices, supporting efficient data exchange and system integration across plant-wide control networks.
Equipped with both 10BaseT and 10Base2 Ethernet ports compliant with IEEE 802.3 CSMA/CD standards, the IC697CMM742 offers flexible network connectivity options for various industrial environments. The module also features multiple diagnostic LEDs for real-time monitoring of communication and operating status, helping improve system visibility and maintenance efficiency.
| Product Name | GE IC697CMM742 Communications Module |
| Manufacturer | General Electric |
| Product Type | Communications Module |
| Part Number | IC697CMM742 |
| Weight | 0.52 kg |
| Estimated shipping dimensions | 4x21.7x29.2cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Internal fuse | 5 x 20mm, 250V, 1.0A, slow acting |
| Module Current Draw | 2.0 Amps (+5 VDC), typical 0.5 Amps (+12 VDC), maximum when powering an external AUI transceiver |
| Network Ports | 10BaseT Port: Ethernet, IEEE 802.3 CSMA/CD 10Base2 Port: Ethernet, IEEE 802.3 CSMA/CD |
| LED Types | MODULE OK, LAN ONLINE, SERIAL ACTIVE, and STATUS LEDs |
| Module Operating Voltage | +5 VDC, +12 VDC |
| Module Current Draw | 2.0 Amps (+5 VDC) |
Dual Ethernet interface support: provides both 10BaseT and 10Base2 connectivity, offering greater flexibility than single-port communication modules
Standards-based networking: IEEE 802.3 compliance ensures reliable industrial Ethernet communication
Enhanced diagnostics: dedicated LEDs simplify troubleshooting and reduce maintenance time
Flexible network integration: supports modern and legacy Ethernet infrastructures within the same automation environment
Reliable industrial design: built for continuous operation in demanding control applications
Compared with similar products: offers broader Ethernet connectivity options and improved network flexibility than many conventional PLC communication modules
Integrated protection: internal fuse helps protect the module from electrical faults and overload conditions
Compared with similar communications modules, the IC697CMM742 provides greater network flexibility, dual Ethernet connectivity, enhanced diagnostics, and reliable industrial performance, making it a strong choice for Ethernet-enabled automation systems.
The IC697CMM742 is fully compatible with GE Fanuc Series 90-70 PLC systems and integrates directly into the PLC architecture as a dedicated communications module. It works seamlessly with Series 90-70 CPUs, I/O modules, and other network-enabled components, providing dependable communication throughout the automation system.
The module interoperates with Ethernet-based industrial devices and software platforms, including HMIs, SCADA systems, engineering workstations, and supervisory control networks. Through its 10BaseT and 10Base2 interfaces, it supports integration with both modern and legacy Ethernet infrastructures, enabling smooth deployment within existing industrial communication environments.
