Product Name: Rack Mount CPU
Brand Name: General Electric
Model Number: IC698CPE010
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | GE IC698CPE010 Rack Mount CPU |
| Manufacturer | General Electric |
| Product Type | Rack Mount CPU |
| Part Number | IC698CPE010 |
| Weight | 0.6 kg |
| Estimated shipping dimensions | 4.4x29.2x19.1cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Boolean Execution Speed | 0.33 ms per 1000 Boolean contacts/coils which |
| IO Memory | 32 Kbits Discrete I/O; 32 KWords Analog I/O |
| CPU Memory | 10 Megabytes of User Logic RAM |
| User Memory | 10 MB user-memory; 10 MB non-volatile memory |
| Built-in Ports | 2 Serial (RS-232, RS-485) 1 Ethernet (Auto 10/100, RJ45) |
| Ethernet data rate | 10Mb/sec and 100Mb/sec |
| Communication ports | Two (2) LAN Ports; Two (2) RS232 / RJ45 Serial port |
| Station Manager Port | One (1) RS232 Station Manager port |
| FTP / Webserver | Supported; Up to 16 connections |
| Media Redundancy | Supported via LAN 2 |
| Current draw | +5 VDC: 4.5 Amps nominal; +12 VDC: 0.042 Amps nominal; -12 VDC: 0.008 Amps nominal |
| RX7i Central Processing Unit | Factory Automation CPU |
| Industrial Automation CPU | PACSystem Controller Module |
| IC698CPE010 Processor | Distributed Control CPU |
| GE Control System CPU | GE Intelligent Platforms CPU |
| Rack Mounted PLC Controller | Emerson RX7i CPU |
| Ethernet PLC CPU | Industrial Ethernet Controller |
| RS232 RS485 CPU Module | PLC Rack CPU Module |
| High Performance PLC Processor | High Memory PLC Controller |
| GE Automation Hardware | Mission Critical CPU Module |
| Industrial Control Processor | Industrial Networking CPU |
The GE IC698CPE010 is a rack-mounted central processing unit designed for the PACSystems RX7i automation platform. It is responsible for executing control logic, managing I/O data, and handling communication tasks within industrial automation systems.
Equipped with high-speed processing capability and large memory capacity, the IC698CPE010 supports complex control applications in manufacturing, process control, and system integration environments. It also provides multiple communication interfaces, enabling flexible connectivity with industrial networks and devices.
PLC Program Execution
Executes control logic for RX7i PACSystems, ensuring real-time automation control.
I/O Data Processing
Processes both discrete and analog I/O data for industrial control operations.
System Memory Management
Manages 32 Kbits of discrete I/O and 32 KWords of analog I/O data handling.
Program Storage Handling
Provides 10 MB user logic RAM and 10 MB non-volatile memory for application storage.
Industrial Network Communication
Supports Ethernet communication at 10/100 Mbps for system networking and data exchange.
Serial Communication Support
Includes RS-232 and RS-485 ports for integration with industrial devices and systems.
Remote Access Functions
Enables FTP and web server capabilities with support for up to 16 connections.
System Redundancy Support
Supports media redundancy via dual LAN ports to improve system reliability.
Inter-Module Coordination
Handles communication and synchronization between rack-mounted modules.
High-Speed Logic Processing
Performs fast Boolean execution for responsive industrial automation control.
Compared with other rack-mounted PLC CPUs, the GE IC698CPE010 offers higher processing capability, larger memory capacity, and advanced communication functions, making it suitable for complex and high-performance automation systems.
High Processing Performance: Supports fast Boolean execution for real-time control applications.
Large Memory Capacity: Provides 10 MB user RAM and 10 MB non-volatile memory for complex programs.
Rich Communication Interfaces: Includes Ethernet, RS-232, and RS-485 for flexible networking.
Dual LAN Redundancy Support: Enhances system reliability through media redundancy capability.
Advanced Connectivity Features: Supports FTP and web server functions for remote access and diagnostics.
Scalable Industrial Architecture: Designed for integration within PACSystems RX7i rack systems.
Reliable Industrial Operation: Suitable for demanding manufacturing and process control environments.
What memory does GE IC698CPE010 have?
The GE IC698CPE010 provides 10 MB user logic RAM and 10 MB non-volatile memory for program storage and data handling.
What communication ports does GE IC698CPE010 support?
The GE IC698CPE010 supports Ethernet (10/100 Mbps), RS-232, and RS-485 communication ports.
Does GE IC698CPE010 support web or remote access?
Yes, the GE IC698CPE010 supports FTP and web server functions with up to 16 connections.
What is the processing capability of GE IC698CPE010?
The GE IC698CPE010 provides high-speed Boolean execution suitable for complex industrial control tasks.
Does GE IC698CPE010 support redundancy?
Yes, the GE IC698CPE010 supports media redundancy through dual LAN ports.
Is GE IC698CPE010 still in production?
The GE IC698CPE010 is part of an older RX7i platform; availability may depend on industrial spare parts suppliers due to lifecycle status.
