Product Name:990 Vibration Transmitter
Brand Name:Bently Nevada
Model Number:990-05-XX-01-CN
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
990-05-XX-01-CN |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Model |
990-05-XX-01-CN |
|
Product Type |
Vibration Transmitter |
|
Input Signal |
3300 NSv Proximity Probe |
|
Output Signal |
4–20 mA DC loop output |
|
Supply Voltage |
+12 to +35 VDC |
|
Full Scale Range |
0–5 mils pp |
|
Frequency Response |
5 Hz – 6,000 Hz |
|
Mounting Type |
DIN rail / Bulkhead |
|
Operating Temperature |
-35°C to +85°C |
|
Storage Temperature |
-52°C to +100°C |
|
Relative Humidity |
Up to 100% condensing |
|
Weight |
0.46kg |
|
System Weight |
0.82 kg |
|
Cable Type |
75Ω coaxial FEP insulated |
|
Dimension (Transmitter) |
10x7.3x5.8cm |
The 990-05-XX-01-CN — 990 Vibration Transmitter is a loop-powered industrial monitoring device designed for converting proximity probe signals into a stable 4–20 mA vibration output. Built for OEM machinery applications, it works with 3300 NSv proximity probes and extension cables to deliver reliable vibration trending data for control and protection systems.
The 990 Vibration Transmitter conditions displacement signals into peak-to-peak vibration values, ensuring consistent performance for pumps, compressors, motors, and fan assemblies. Its integrated Proximitor functionality, compact design, and simplified wiring structure make it suitable for space-limited installations.
With DIN-rail or bulkhead mounting options, the 990-05-XX-01-CN provides robust operation in industrial environments. It supports diagnostic access via PROX OUT, ensuring efficient system checks while maintaining stable loop output for machinery monitoring applications.
Q1: What probe type is compatible with 990-05-XX-01-CN?
A1: It is compatible with 3300 NSv proximity probes and matching extension cables.
Q2: What is the output signal of the 990 transmitter?
A2: It provides a standard 4–20 mA DC loop output proportional to vibration levels.
Q3: Can the 990 transmitter be used in humid environments?
A3: Yes, it supports up to 100% condensing humidity with proper connector protection.
Q4: What mounting options are available?
A4: The device supports DIN-rail clips and bulkhead screw mounting configurations.
Q5: What is the main application of this transmitter?
A5: It is mainly used for vibration monitoring in compressors, pumps, motors, and industrial rotating equipment.
| Number | Description |
|---|---|
| 123266-01 | Coaxial Cable Kit, includes 4 cables, each 1.5 m (5 ft) length |
| 02211505 | Single coaxial cable, 1.5 m (5 ft) length |
| 01810700 | 9V alkaline battery for test adapter |
| 02270056 | AC adapter, universal AC input to 9V DC output (120/240 VAC compatible) |
| 02198937 | North American power cord for AC adapter |
| 123133 | 990 Test Adapter User Guide manual |
| 02173006 | Bulk field cable, 1.0 mm² (18 AWG), 2-conductor shielded twisted pair |
| 123655 | 990/991 transmitter system installation user guide |
| 330153-05 | Cable connector kit with 75Ω connectors, shrink tubing, isolator seal |
| 163356 | Connector crimp tool kit with ClickLoc inserts and installation guide |
| 330951-01 | 990 mounting screw kit, includes 4 replacement screws |
| 284726 | DIN rail mounting kit for 35 mm rail installation |
