Product Name: Ethernet Interface Module
Brand Name: General Electric
Model Number: IC698ETM001
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | GE IC698ETM001 Ethernet Interface Module |
| Manufacturer | General Electric |
| Product Type | Ethernet Interface Module |
| Part Number | IC698ETM001 |
| Weight | 0.36kg |
| Estimated shipping dimensions | 2.1x17.3x29.3cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| LAN | IEEE 802.2 Logical Link Control Class I IEEE 802.3 CSMA/CD Medium Access Control 10/100 Mbps |
| LED Indicators | MODULE OK LAN ONLINE STATUS 100, LINK P1 100, LINK P2 |
| Module Operating Temperature | 0 Deg. Celsius to +60 Deg. Celsius |
| Serial Port (Station Mgr Port) | RS-232 DCE, 1200 - 115200 bps. D-connector, 9-pin female |
| Speed | 200 MHz |
| Voltage | 5 Volts DC |
| Current | 1.2 Amperes |
| Connector and Cable | 10 Base T/100 Base Tx, RJ 45 |
| Maximum Number of IP Addresses | One |
| GE Network Communication Card | RS232 Communication Interface |
| PLC Ethernet Adapter | Factory Automation Network Module |
| 10/100 Mbps Ethernet Module | Industrial Data Communication Device |
| RJ45 Industrial Network Module | GE Intelligent Platforms Ethernet |
| GE Automation Communication Hardware | Emerson RX7i Communication Module |
| Industrial Control Networking Module | Control System Network Interface |
| Ethernet TCP/IP PLC Module | PLC Network Expansion Module |
| GE RX7i Interface Module | Industrial Ethernet Gateway Module |
| Station Manager Module | GE PLC Communication Module |
The GE IC698ETM001 is an Ethernet interface module designed for the PACSystems RX7i platform. It enables reliable network communication between the PLC system and industrial Ethernet networks, supporting real-time data exchange and remote system access.
With support for 10/100 Mbps Ethernet communication and integrated station management capabilities, the IC698ETM001 ensures stable and efficient connectivity in industrial automation environments. It is widely used in factory automation, process control, and distributed control systems requiring secure and fast network communication.
Industrial Ethernet Communication
Provides 10/100 Mbps Ethernet connectivity based on IEEE 802.3 standards for industrial networking.
PLC Network Integration
Enables communication between RX7i PLC systems and external industrial devices over Ethernet networks.
Station Management Access
Includes RS-232 station manager port for configuration, diagnostics, and system maintenance.
Status Monitoring
LED indicators display MODULE OK, LAN ONLINE STATUS, and link status for ports P1 and P2.
IP Communication Handling
Supports one IP address for controlled and secure network communication.
Network Interface Support
Uses RJ45 connectors for 10Base-T and 100Base-TX Ethernet connections.
Real-Time Data Exchange
Facilitates fast and reliable data transmission between control systems and networked devices.
Industrial Environment Operation
Designed to operate in temperatures from 0°C to +60°C for stable performance in harsh conditions.
Compared with other Ethernet interface modules, the GE IC698ETM001 offers stable industrial communication, simple configuration, and reliable diagnostics, making it suitable for RX7i networked automation systems.
Stable Industrial Ethernet Performance: Supports 10/100 Mbps communication for reliable data transfer.
Clear Status Indication: LED indicators provide real-time network and module status monitoring.
Easy System Integration: Designed specifically for GE RX7i platforms for seamless compatibility.
Built-in Diagnostics Access: RS-232 station manager port simplifies configuration and troubleshooting.
Robust Industrial Design: Operates reliably in temperatures from 0°C to +60°C.
Efficient Network Connectivity: Supports standard RJ45 Ethernet interfaces for easy installation.
Controlled IP Communication: Uses a single IP address for stable and secure network operation.
What Ethernet speeds does GE IC698ETM001 support?
The GE IC698ETM001 supports 10 Mbps and 100 Mbps Ethernet communication.
How many IP addresses does GE IC698ETM001 support?
The GE IC698ETM001 supports one IP address for network communication.
What ports are available on GE IC698ETM001?
The GE IC698ETM001 includes RJ45 Ethernet ports and a 9-pin RS-232 station manager port.
What is the operating temperature of GE IC698ETM001?
The GE IC698ETM001 operates in a temperature range from 0°C to +60°C.
What indicators are available on GE IC698ETM001?
The GE IC698ETM001 includes MODULE OK, LAN ONLINE STATUS, and link status LEDs.
Is GE IC698ETM001 suitable for industrial environments?
Yes, the GE IC698ETM001 is designed for reliable operation in industrial automation and control systems.
