Product Name:Contact Input Terminal Board
Brand Name: GE
Model Number:IS200TBCIH1BBC
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
General Electric |
Model Number: |
IS200TBCIH1BBC |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Part Number |
IS200TBCIH1BBC |
|
Manufacturer |
GE / GE Fanuc |
|
Series |
Mark VI Speedtronic |
|
Product Type |
Contact Input Terminal Board |
|
Input Channels |
24 dry contact inputs (2× barrier terminal blocks) |
|
Input Type |
Dry contact (externally powered) |
|
Nominal Excitation Voltage |
125 V DC (100–145 V DC) |
|
Channel Voltage Rating |
Up to 250 V AC/DC |
|
Channel Current Rating |
10 A continuous |
|
Operating Temperature |
–30°C to +65°C |
|
Dimensions |
33x10x5cm |
|
Weight |
Approx. 0.55 kg |
|
Mounting |
Side-mount bracket (VME rack) or DIN rail |
|
Connectors |
JR1 (simplex) / JR1+JS1+JT1 (TMR) |
|
Protection |
Noise suppression circuitry |
|
Country of Origin |
USA |
|
Availability |
In Stock |
The IS200TBCIH1BBC is a contact input terminal board (TBCI) from GE‘s Mark VI Speedtronic series. The IS200TBCIH1BBC terminates 24 dry contact field signals from switches, pushbuttons, and limit switches, converting them into optically isolated logic‑level inputs for the Mark VI controller. The IS200TBCIH1BBC features noise suppression circuitry and supports simplex or TMR configurations. JR1 is used for simplex; all three JR1, JS1, JT1 are used for TMR.
Terminating dry contact inputs in GE Mark VI gas/steam turbine control systems
Connecting limit switches, pushbuttons, and protective relay contacts to the VME rack
Signal acquisition in simplex or TMR configurations
24 dry contact inputs (two 24‑terminal barrier blocks)
Optical isolation with group isolation for field‑to‑logic separation
Noise suppression circuitry (surge and high‑frequency filtering)
Supports simplex (JR1) or TMR (JR1+JS1+JT1) configurations
LED indicators for power and channel status
DIN rail or side‑mount bracket installation
Terminates and conditions 24 dry contact field signals for the Mark VI controller
Provides optical isolation between field inputs and backplane logic
Suppresses electrical noise and surges on input lines
Supports simplex and TMR configurations via JR1/JS1/JT1 connectors
Q1: What is the IS200TBCIH1BBC ?
A1: A 24‑channel contact input terminal board for GE Mark VI turbine control systems.
Q2: How many inputs does it have?
A2: 24 dry contact inputs on two barrier terminal blocks.
Q3: What voltage does it use?
A3: 125 V DC excitation voltage with noise suppression circuitry.
Q4: Does it support TMR?
A4: Yes — use JR1 (simplex) or JR1, JS1, JT1 (TMR).
Q5: How is it installed?
A5: Side‑mount bracket to VME rack or DIN rail mounting.
