Product Name: Relay Output Module
Brand Name: GE
Model Number:IS230TRLSH2B/IS200TRLYS1BGG
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
General Electric |
Model Number: |
IS230TRLSH2B/IS200TRLYS1BGG |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
IS200TRLYS1BGG |
IS230TRLSH2B |
|
Manufacturer |
General Electric (GE) |
General Electric (GE) |
|
Product Series |
Mark VI Speedtronic™ |
Mark VIe Speedtronic™ |
|
Product Type |
Discrete I/O Board (Barrier-type) |
Relay Output Module |
|
Relay Type |
Plug-in magnetic relays, Form C contacts |
Electromechanical relays (SPDT/DPDT options) |
|
Number of Relays |
Multiple along board center |
|
|
Primary Diagnostic Function |
||
|
Contact Rating |
Form C (SPDT) |
|
|
Voltage Rating |
||
|
Power Supply |
From backplane |
|
|
Communication |
Hardwired discrete I/O |
Dual Ethernet ports (RJ45) |
|
Connectors |
DC-37 pin interface |
|
|
Protection Features |
7× MOVs for voltage spike/surge protection |
|
|
Mounting |
Rack-mount (Mark VI chassis) |
|
|
Operating Temperature |
0°C to +60°C |
|
|
Storage Temperature |
–40°C to +85°C |
|
|
Humidity |
5% to 95% non-condensing |
|
|
Dimensions (approx.) |
136 × 89 × 25 mm (5.35 × 3.5 × 1 in) |
|
|
Weight |
||
|
Safety Certification |
— |
|
|
Country of Origin |
USA |
The GE IS200TRLYS1BGG is a discrete I/O board engineered for the Mark VI Speedtronic™ turbine control system, featuring plug‑in magnetic Form C relays for coil current diagnostics. The GE IS230TRLSH2B is a high‑integrity relay output module for the Mark VIe platform, converting digital logic commands into physical relay actuation for field devices. With 12–16 isolated relay channels, dual Ethernet communication, and SIL 2 certification, the IS230TRLSH2B provides predictive maintenance features such as contact bounce detection. Both modules are built with robust industrial-grade construction and conformal coating for harsh environments.
Gas and steam turbine control – discrete I/O and relay actuation for Speedtronic systems
Power generation – turbine bypass valves, combined‑cycle plant control, emergency shutdown sequences
Oil & gas – wellhead isolation valves, compressor station control, offshore platform safety systems
Water and wastewater treatment – pump coordination, chemical dosing, valve actuation
Industrial automation – motor control centers, contactor switching, alarm annunciation
Form C relay outputs (IS200TRLYS1BGG) – plug‑in magnetic relays with form C contacts for flexible switching configurations
Coil current diagnostics (IS200TRLYS1BGG) – real‑time health monitoring of relay outputs; contact voltage diagnostics available on H1C variant
High‑density relay channels (IS230TRLSH2B) – 12–16 isolated relay outputs supporting SPDT/DPDT configurations
Predictive maintenance (IS230TRLSH2B) – coil voltage monitoring and contact bounce detection reduce unplanned outages
Dual Ethernet communication (IS230TRLSH2B) – redundant RJ45 ports for reliable network integration
SIL 2 safety certification (IS230TRLSH2B) – TÜV‑approved for safety‑critical processes
Surge protection (IS230TRLSH2B) – 7× MOVs protect against voltage spikes and surges
Partial power protection (IS200TRLYS1BGG) – applicable in 120/240 VAC systems
Wide temperature range – –40°C to +70°C operation for harsh industrial environments
Conformal coating – protects against moisture, dust, and chemical contaminants
Converts digital commands to relay actuation – translates control logic signals into physical switching for field devices
Provides discrete I/O interfacing (IS200TRLYS1BGG) – bridges field‑side actuators with the Mark VI controller
Performs coil current diagnostics (IS200TRLYS1BGG) – monitors relay coil integrity for proactive maintenance
Executes high‑integrity relay switching (IS230TRLSH2B) – controls motors, valves, pumps, and alarms via dry contact relays
Monitors relay health (IS230TRLSH2B) – detects contact wear and bounce, providing real‑time feedback for maintenance scheduling
Supports redundant communication (IS230TRLSH2B) – dual Ethernet ports ensure continuous operation during network faults
Q1: What is the difference between IS200TRLYS1BGG and IS230TRLSH2B?
A1: The IS200TRLYS1BGG is a discrete I/O board for the Mark VI system with plug‑in magnetic Form C relays for coil current diagnostics. The IS230TRLSH2B is a relay output module for the Mark VIe platform with 12–16 isolated relay channels, dual Ethernet communication, and SIL 2 certification.
Q2: What is the contact rating of the relays on the IS200TRLYS1BGG?
A2: The IS200TRLYS1BGG uses Form C (SPDT) plug‑in magnetic relays with a contact rating of 5 A at 30 V DC or 5 A at 250 V AC.
Q3: Is the IS230TRLSH2B suitable for safety‑critical applications?
A3: Yes. The IS230TRLSH2B is TÜV SIL 2 certified (IEC 61508), making it suitable for safety‑critical processes such as turbine overspeed protection and emergency shutdown systems.
Q4: Can the IS200TRLYS1BGG be used for contact voltage diagnostics?
A4: No. The IS200TRLYS1BGG is specifically designed for coil current diagnostics. For contact voltage diagnostics, use a TRLY board ending in H1C.
Q5: What protection features does the IS230TRLSH2B include?
A5: The IS230TRLSH2B is equipped with seven Metal Oxide Varistors (MOVs) to protect against voltage spikes and surges, enhancing operational safety and extending equipment life.
