Product Name: Thermal power resistance input module
Brand Name: GE
Model Number:IS200SRTDH2ACB/IS230SNRTH2A
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
General Electric |
Model Number: |
IS200SRTDH2ACB/IS230SNRTH2A |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
IS200SRTDH2ACB |
IS230SNRTH2A |
|
Manufacturer |
General Electric (GE) |
General Electric (GE) |
|
Product Series |
Mark VI Speedtronic™ |
Mark VIe Speedtronic™ |
|
Product Type |
RTD Input Terminal Board |
RTD Input Module / I/O Pack |
|
RTD Channels |
||
|
Sensor Compatibility |
||
|
Wiring Configuration |
||
|
Accuracy |
||
|
Measurement Range |
-200°C to +850°C |
|
|
Isolation |
Channel-to-system isolated |
|
|
Input Voltage |
||
|
Power Consumption |
||
|
Operating Temperature |
||
|
Storage Temperature |
||
|
Mounting |
||
|
Dimensions (H×W×D) |
||
|
Weight |
||
|
Communication |
||
|
Certifications |
||
|
Country of Origin |
USA |
USA |
The GE IS200SRTDH2ACB is an RTD input terminal board engineered for the Mark VI Speedtronic™ turbine control system, providing eight isolated channels for precision temperature monitoring of bearings, exhaust gas, and lubrication systems. The GE IS230SNRTH2A is a Mark VIe RTD input module that delivers four high-accuracy channels with ±0.1°C precision, interfacing directly with the Mark VIe DCS via dual redundant IONet Ethernet ports. Both modules support Pt100/Pt1000 sensors with 2/3/4-wire configuration, feature rugged conformal coating for harsh environments, and enable hot-swappable replacement to minimize system downtime.
Power generation – gas/steam turbine bearing temperature monitoring, exhaust gas measurement, lube oil systems
Oil & gas – compressor stations, pipeline monitoring, offshore platforms
Industrial manufacturing – steel mills, furnace temperature control, process pipelines
Marine propulsion – shipboard turbine temperature monitoring
Generator excitation systems – EX2100e excitation control temperature feedback
Motor protection systems – standalone temperature monitoring for Multilin 369 and M60
High-precision temperature measurement – ±0.1°C accuracy ensures reliable thermal data for critical turbine components
Flexible sensor compatibility – supports Pt100, Pt1000, Ni120, and Cu100 RTDs with 2/3/4-wire configuration
Galvanic isolation – 2.5 kV RMS channel-to-channel isolation eliminates ground loops and EMI interference
Rugged environmental protection – conformal-coated PCB withstands -40°C to +85°C, moisture, dust, and chemical contaminants
Hot-swappable design – enables module replacement without system shutdown, reducing maintenance downtime
Front-panel LED diagnostics – real-time status indicators for power, communication, and per-channel faults
Auto-zero calibration – eliminates wire loop errors and ensures long-term measurement stability
Surge and reverse polarity protection – withstands transient voltages up to 6 kV
Flexible mounting – 35 mm DIN rail or panel-mount with pluggable terminal blocks
Converts RTD resistance to digital signals – translates analog resistance changes from Pt100/Pt1000 sensors into digital values for turbine control algorithms
Provides high-accuracy temperature monitoring – delivers ±0.1°C precision for bearings, exhaust gas, and lube oil systems
Isolates sensor inputs from electrical noise – 2.5 kV RMS galvanic isolation eliminates ground loops and EMI interference
Communicates with turbine controller – interfaces with PRTD I/O packs (IS200SRTDH2ACB) or Mark VIe DCS via IONet (IS230SNRTH2A)
Performs continuous self-diagnostics – monitors sensor health, detects open circuits and signal drift, and alerts operators via LED indicators
Q1: What is the difference between IS200SRTDH2ACB and IS230SNRTH2A?
A1: The IS200SRTDH2ACB is an RTD terminal board for Mark VI systems with 8 channels. The IS230SNRTH2A is an RTD input module for Mark VIe systems with 4 channels and IONet communication.
Q2: What RTD sensors are compatible with the IS200SRTDH2ACB?
A2: The IS200SRTDH2ACB supports Pt100, Pt1000, Ni120, and Cu100 RTDs with 2-wire, 3-wire, or 4-wire configuration.
Q3: Can the IS230SNRTH2A be replaced while the system is running?
A3: Yes. The IS230SNRTH2A supports hot-swapping, allowing module replacement during operation without system shutdown.
Q4: What is the accuracy of the IS200SRTDH2ACB?
A4: The IS200SRTDH2ACB provides ±0.1°C accuracy in the 0–100°C range and ±0.2°C across the full -200°C to +600°C range.
Q5: How does the IS230SNRTH2A communicate with the control system?
A5: The IS230SNRTH2A communicates via dual redundant Ethernet ports (IONet) to the Mark VIe DCS, ensuring data integrity during network outages.
