Product Name: Replacement Cap Pack module
Brand Name: GE
Model Number:IC695ACC412
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
General Electric |
Model Number: |
IC695ACC412 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Part Number |
IC695ACC412 (also IC695ACC412-AA) |
|
Manufacturer |
GE Fanuc (now Emerson Automation) |
|
Series |
PACSystems™ RX3i |
|
Product Type |
Replacement Cap Pack Module (capacitor-based) |
|
Role |
Replacement capacitor pack for Energy Pack IC695ACC402 |
|
Compatible CPU |
IC695CPE330 only |
|
Energy Storage |
Industrial lithium capacitor array (no chemical battery) |
|
Back-up Trip Voltage |
19 V DC ±4% / 16.7 V DC ±4% (source-dependent) |
|
Charge Time |
60–90 minutes to full charge |
|
Memory Retention Time |
Approximately 60 seconds on full charge |
|
Life Expectancy |
5 years (installed, standard conditions) |
|
Shelf Life |
1 year (uninstalled) |
|
LED Indicators |
Single green STAT LED (blinking = charging, solid = ready/fully charged) |
|
Operating Temperature |
0°C to +60°C (some: –25°C to +60°C) |
|
Storage Temperature |
–40°C to +85°C |
|
Temperature Code |
T4A |
|
Hazardous Location Rating |
Class I, Division 2, Groups A, B, C, D |
|
Protection Class |
IP20 |
|
Dimensions |
3.5 × 13.5 × 13.5 cm (1.38″ × 5.31″ × 5.31″) |
|
Weight |
0.24 – 0.29 kg (approx. 0.53 lb) |
|
Mounting |
Screwed into the bottom of the IC695ACC402 Energy Pack |
|
Required Cable |
IC695CBL002 / IC695CBL002A (replacement cable, order separately) |
|
Firmware |
No independent firmware – updated via CPE330 CPU |
|
Compliance |
UL, CSA, CE, RoHS, suitable for hazardous locations |
|
Country of Origin |
United States (USA) |
|
Availability |
In Stock |
The IC695ACC412 is a capacitor‑based replacement pack designed by GE Fanuc for the PACSystems RX3i Energy Pack (IC695ACC402). When the internal capacitors of an existing ACC402 reach end‑of‑life, the IC695ACC412 serves as a direct drop‑in replacement, restoring the energy pack‘s full backup capability for the CPE330 CPU. Unlike conventional batteries, the IC695ACC412 contains no chemical cells and requires no scheduled replacement wiring changes. The IC695ACC412 plugs directly into the ACC402 base and accepts charging current via the RX3i backplane. With a typical 5‑year service life and support for live field replacement, the IC695ACC412 helps maintain continuous power protection for critical automation data.
Preventive maintenance renewal of aging capacitor packs in RX3i CPE330 systems
Emergency restoration after complete energy pack failure in a live production line
Long‑service industrial automation where capacitors have naturally reached end‑of‑life
Retrofit and upgrade of legacy PACSystems installations to restore memory backup capacity
Remote or unmanned stations (oil & gas, water treatment, renewable energy monitoring)
Hazardous location applications (Class I, Division 2, Groups A–D)
Capacitor‑based storage: No chemical battery; eliminates battery‑replacement cycles and disposal compliance burdens.
Direct drop‑in replacement for aging energy packs: Repairs an existing ACC402 when its internal capacitors have aged or failed, without requiring a full system re‑engineering.
Fully compatible with CPE330 CPU only: Electrical and physical parameters matched specifically to the ACC402 / CPE330 combination; explicitly not compatible with ACC400, ACC403, CPE305, CPE310, CPE400 or CPL410.
~60 seconds backup time on full charge: Delivers enough holdup power to allow an orderly RAM‑to‑flash transfer before the controller loses all volatile data.
Live recharge from backplane: Passively charged by the RX3i backplane 24 V DC line while the system is running; no external programming, calibration, or maintenance routine required.
Single green STAT LED: Visual indicator for charging status (fast blinking during charge, solid green when fully charged and ready).
Hot‑swap capable (base‑dependent): Cap pack can be replaced while the base energy pack remains powered, provided the replacement procedure is performed within the factory guidelines.
UL / CSA / CE / RoHS certified and Class I Div 2 rated: Approved for installation in hazardous areas with T4A temperature code and IP20 enclosure, suitable for harsh industrial environments.
Stores electrical charge from the RX3i backplane during normal operation and releases stored energy to the CPE330 controller when input voltage falls below the configured backup trip threshold.
Extends the service life of an existing ACC402 energy pack by replacing aged capacitor cells without discarding the entire base assembly.
Provides approximately 60 seconds of continued power after main supply failure, during which the CPE330 can save runtime data to non‑volatile flash memory and perform a clean program halt.
Reports its own charge status and health via a single green LED and through CPU fault table entries when nearing end‑of‑life.
Electrically isolates the capacitor bank from the backplane during normal charging to prevent over‑current draw and thermal stress.
Q1: What is the IC695ACC412 used for?
A1: The IC695ACC412 is a replacement capacitor pack that restores the backup capability of a PACSystems RX3i Energy Pack (IC695ACC402) when its original capacitors have reached end‑of‑life.
Q2: Which CPU is compatible with the IC695ACC412?
A2: The IC695ACC412 works exclusively with the PACSystems RX3i CPE330 CPU. It is not compatible with CPE305, CPE310, CPE400, CPL410, or any other RX3i or RXi controller.
Q3: Does the IC695ACC412 contain a chemical battery?
A3: No. The IC695ACC412 uses an industrial‑grade lithium capacitor array and contains no conventional chemical battery, eliminating battery‑specific maintenance and disposal concerns.
Q4: How long does the IC695ACC412 last before replacement?
A4: The IC695ACC412 has a typical installed service life of 5 years under normal operating conditions. Storage life before installation is 1 year; after that, the pack should not be used.
Q5: Is the IC695ACC412 hot‑swappable?
A5: Yes. The IC695ACC412 can be replaced while the system is powered, provided the replacement procedure is followed correctly. However, do not remove power during a firmware update of the energy pack; consult the factory manual for step‑by‑step guidelines.
