General Electric IC693ALG222 Analog Voltage Input Module

General Electric IC693ALG222 Analog Voltage Input Module

Product Name: Analog Voltage Input Module

Brand Name: General Electric

Model Number: IC693ALG222

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

general electric ic693alg222 analog voltage input module-1

Overview
Specifications
Commercial Terms
Contact Us
Advantages
FAQ
Why Choose Us
Major Business
Recommended Products

Overview

The General Electric IC693ALG222 Analog Voltage Input Module is a high-performance analog voltage input module designed for Series 90-30 PLC systems. It features 16 single-ended or 8 differential input channels, selectable unipolar and bipolar voltage ranges, channel-by-channel configuration, 1500 VAC isolation, and a removable 20-terminal screw terminal block for flexible installation. Designed to provide accurate multi-channel analog signal acquisition, the module enhances process monitoring, improves measurement reliability, and simplifies system configuration. Its seamless compatibility with Series 90-30 PLC platforms makes it an ideal solution for process automation, manufacturing, power generation, water treatment, and industrial control applications.

Specifications

Product Name	General Electric IC693ALG222 Analog Voltage Input Module
Manufacturer	General Electric
Product Type	Analog Voltage Input Module
Part Number	IC693ALG222
Place of shipment	Xiamen, China
Country of origin	USA
Input Channels	16 single-ended (selectable) or 8 differential (selectable)
Input Signal Type	Analog Voltage
Input Voltage Range	0 to +10 VDC (Unipolar), −10 to +10 VDC (Bipolar), selectable per channel
Resolution	2.5 mV/LSB (0 to +10 V), 5 mV/LSB (−10 to +10 V)
Update Rate	6 ms (16 single-ended channels), 3 ms (8 differential channels)
Absolute Accuracy	±0.25% FS @ 25°C, ±0.5% FS over operating temperature range
Linearity	< 1 LSB
Isolation	1500 VAC between field side and logic side
Common Mode Voltage	±11 V (Differential mode)
Cross-Channel Rejection	>80 dB (DC to 1 kHz)
Input Impedance	>500 kΩ (Single-ended), >1 MΩ (Differential)
Input Filter Response	41 Hz (Single-ended), 82 Hz (Differential)
Internal Power Consumption	112 mA max from +5 VDC backplane bus; 41 mA max from isolated +24 VDC backplane supply
Configuration	Channel-by-channel selectable input range and mode
Alarm Functions	High and Low alarm limits configurable for each channel
Data Scaling	0 V = 0 counts, +10 V = +32000 counts (Unipolar); −10 V = −32000 counts, 0 V = 0 counts, +10 V = +32000 counts (Bipolar)
Connector	Removable 20-terminal screw terminal block
Installation	Fits any I/O slot of a 5-slot or 10-slot Series 90-30 PLC baseplate
LED Indicators	MODULE OK, Power Supply OK
Application	Multi-channel analog voltage acquisition for Series 90-30 PLC systems

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock
