General Electric IC693MDL930 Isolated Relay Output Module

General Electric IC693MDL930 Isolated Relay Output Module

Product Name: Isolated Relay Output Module

Brand Name: General Electric

Model Number: IC693MDL930

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

general electric ic693mdl930 isolated relay output module-1

Overview
Product Parameters
Commercial Terms
Contact Us
Why Choose US
Major Business
Product Feature
FAQ
Recommended Products

Overview

The General Electric IC693MDL930 Isolated Relay Output Module is an 8-channel relay output module designed for reliable switching of AC and DC loads in GE Series 90-30 PLC systems. Featuring eight isolated relay outputs, it supports operating voltages from 5–30 VDC and 5–250 VAC (50/60 Hz), making it suitable for controlling motors, solenoids, contactors, valves, and other field devices. The module provides 1,500 V isolation between the field and logic sides, fast response times of 15 ms maximum, and high switching capacity of up to 4 A resistive per output. Its robust electrical isolation and flexible load compatibility make it an ideal solution for demanding industrial automation applications.

Product Parameters

Product Name	General Electric IC693MDL930 Isolated Relay Output Module
Manufacturer	General Electric
Product Type	Isolated Relay Output Module
Part Number	IC693MDL930
Weight	0.34kg
Estimated shipping dimensions	3.5x13x13.5cm
Place of shipment	Xiamen, China
Country of origin	USA
Rated Voltage	24 V DC, 120/240 V AC (Nominal)
Operating Voltage	5–30 V DC; 5–250 V AC, 50/60 Hz
Outputs per Module	8 Isolated Outputs
Isolation	1500 V between Field Side and Logic Side; 500 V between Groups
Maximum Load	4 A Resistive per Output; 2 A Pilot Duty per Output; 20 A Maximum per Module (UL Installations)
Minimum Load	10 mA
Maximum Inrush Current	5 A
On Response Time	15 ms Maximum
Off Response Time	15 ms Maximum
Internal Power Consumption	6 mA (All Outputs On) from 5 V Backplane Bus; 70 mA (All Outputs On) from 24 V Relay Backplane Bus

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales:	Email:	Whatsapp:
Jim Pei	[email protected]	+86 18020776782

Why Choose US

✔ Genuine Industrial Automation Products
✔ Strict Quality Inspection Before Shipment
✔ Competitive Prices & Flexible Quotations
✔ Large Inventory with Fast Global Shipping
✔ 12-Month Warranty on Eligible Products
✔ Professional Technical & After-Sales Support
✔ Inquiry Response Within 1 Hour
✔ Secure Packaging for International Shipping
✔ Trusted Supplier for PLC, DCS, HMI, and Industrial Control Systems

Major Business

ABB: Industrial robot parts of DSQC series,Bailey INFI90, DCS
Honeywell: 51/MU/MC/TC/CC ...
Triconex: 3008/3511/3625/3664/3721/3700A..
Bently Nevada: 3500/3300/330180-Cable..
Foxboro: FBM203/204/217/231, FCP240/270
Woodward: SPC valve position controller, PEAK15 digital controller
Siemens: 6DD/6DP/6ES5/6DR/6GK Series
Westinghouse Series: 1C/5X ...
General electric: IC693/IC697/IC695/DS200..
Schneider: 140 Series

Product Feature

Eight Isolated Relay Outputs
Provides eight independently isolated relay outputs for reliable control of multiple field devices.
Wide AC and DC Switching Range
Supports operating voltages from 5–30 VDC and 5–250 VAC at 50/60 Hz.
High Switching Capacity
Handles resistive loads up to 4 A per output and a maximum module load of 20 A for UL installations.
Superior Electrical Isolation
Offers 1,500 V isolation between the logic and field circuits, with 500 V isolation between output groups.
Fast Relay Response
Delivers maximum on and off response times of 15 ms for responsive output control.
Low Backplane Power Consumption
Minimizes controller loading with efficient power consumption from both the 5 V and 24 V backplane buses.
Flexible Industrial Applications
Suitable for switching contactors, relays, indicator lamps, valves, solenoids, and other industrial loads.
Reliable PLC Integration
Designed for seamless integration into compatible General Electric Series 90-30 automation systems.

FAQ

---What is the IC693MDL930 used for?
IC693MDL930 is used to control AC and DC field devices through eight isolated relay outputs in industrial PLC systems.

---What is the maximum module load supported by the IC693MDL930?
IC693MDL930 supports a maximum combined module load of 20 A for UL installations.

---What is the minimum load requirement for the IC693MDL930?
IC693MDL930 requires a minimum load of 10 mA for reliable relay operation.

---Can the IC693MDL930 switch both AC and DC loads?
IC693MDL930 is designed to switch both AC and DC loads within its specified operating voltage range.

---What applications are suitable for the IC693MDL930?
IC693MDL930 is commonly used for controlling contactors, relays, solenoid valves, motors, indicator lights, and other industrial field devices.

---Why is electrical isolation important in the IC693MDL930?
IC693MDL930 uses high-voltage isolation to protect the PLC logic from electrical disturbances generated by field wiring and connected equipment.
