Product Name:DC INPUT CARD
Brand Name:Honeywell
Model Number:05701-A-0325
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
05701-A-0325 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Description |
|
Model |
05701-A-0325 |
|
Product Type |
DC Input Card |
|
Rated Input |
24 VDC nominal |
|
Output Distribution |
Backplane power routing |
|
Protection |
Fuse, reverse polarity protection |
|
Isolation |
PSU / AUX diode isolated |
|
Terminal Blocks |
TB1 / TB2 dual access |
|
Operating Temp |
0 to 60°C |
|
Storage Temp |
-40 to 85°C |
|
Dimensions |
13x11.8x1.8cm |
|
Weight |
0.15kg |
|
Mounting |
Rack / sub-rack system |
The 05701-A-0325 DC Input Card is designed to provide reliable 24VDC power distribution for rack-based control systems within industrial automation environments. It serves as the primary power entry point, routing external DC supply through the system backplane to all connected modules, ensuring stable operation across the entire sub-rack architecture.
The unit supports dual power input options including PSU and auxiliary feeds, with diode isolation to prevent reverse current flow. Built-in fuse protection enhances system safety, while RFI filtering ensures stable performance in electrically noisy industrial environments. The card also integrates TB1 and TB2 terminal interfaces for flexible wiring and engineering module communication.
In advanced configurations such as the 05701-A-0325, power can be optimized for high-load systems by distributing supply through relay interface cards, making it suitable for scalable control architectures and mission-critical automation systems.
Q1: What is the function of 05701-A-0325 DC Input Card?
A1: It distributes 24VDC power to rack-based control system modules through the backplane.
Q2: Does the module support backup power input?
A2: Yes, it supports auxiliary DC input for standby or backup power operation.
Q3: Is the DC Input Card protected against faults?
A3: Yes, it includes fuse protection and reverse polarity safeguards.
Q4: Can it be used in industrial environments?
A4: Yes, it is designed for harsh industrial automation and control systems.
Q5: What isolation features are included?
A5: PSU and AUX inputs are diode-isolated to prevent cross-power interference.
| number | describe |
|---|---|
| 05701-M-5006 | System 57 Control System Modbus Interface Option, supports RS485/RS422 communication for industrial data integration and remote monitoring |
| 05701-M-5007 | System 57 Control System Event Printing Option, RS232-based module for real-time event logging and printing in control systems |
| 05701-M-5009 | System 57 Control System Alarm Update Option, provides alarm status updating and system notification enhancement for process safety monitoring |
