Product Name: Power Supply Distribution (PSD) Module
Brand Name: Honeywell
Model Number: 10303/1/1
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
| Product Name | Honeywell 10303/1/1 Power Supply Distribution (PSD) Module |
| Manufacturer | Honeywell |
| Product Type | Power Supply Distribution (PSD) Module |
| Part Number | 10303/1/1 |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Power Requirement | None |
| Output Voltage | 5 VDC |
| Maximum Current | 20 A (Module Dissipation Limit) |
| Maximum Current (Modules Without Suffix Code) | 12 A |
| Maximum Forward Voltage Drop | 0.55 V |
| Maximum Reverse Voltage | 30 V |
| Connector Type | DIN 41612-H 15P (Faston) |
| Maximum Connector Current | 10 A per Pin |
| Space Requirement | 4 TE, 3 HE (4 HP, 3U) |
| Installation Requirement | Install PSD Modules Adjacent to PSU Modules to Minimize Voltage Drop |
| Minimum Wire Size | 2.5 mm² (AWG 14) |
| Service Requirement | Replace Module Only with Associated PSU Switched Off |
| Approvals | CE, TÜV, UL |
| Required Quantity | One PSD Module per PSU Module |
| Application | Redundant Central Parts with Non-Redundant I/O |
|
Sales |
|
Phone/Whatsapp |
|
Jim Pei |
The Honeywell 10303/1/1 Power Supply Distribution (PSD) Module is a robust power supply distribution module designed to distribute 5 VDC power within Honeywell industrial control systems. It features high-current power distribution, DIN 41612-H 15P connectors, support for up to 20 A current capacity, and a compact 4 TE, 3 HE form factor for efficient cabinet installation. Designed to ensure stable power delivery between power supply units and system components, the module improves power distribution efficiency, supports redundant system architectures, and enhances overall system reliability. It is an ideal solution for process automation, power generation, manufacturing, and other mission-critical industrial control applications.
5 VDC Power Distribution
Distributes regulated 5 VDC power from the power supply unit to connected system modules, ensuring reliable power delivery throughout the control system.
High-Current Power Transfer
Supports high-current distribution to meet the power requirements of multiple industrial control modules while maintaining dependable electrical performance.
Power Supply Interface
Provides a dedicated interface between power supply units and system backplanes, simplifying power routing within Honeywell control cabinets.
Supports Redundant Power Architectures
Facilitates power distribution in systems utilizing redundant central components with non-redundant I/O configurations, improving system availability and operational continuity.
Minimizes Distribution Voltage Loss
Designed for installation adjacent to the associated power supply module to reduce voltage drop and maintain stable operating conditions across the system.
Reliable Industrial Power Management
Enhances overall power distribution reliability for Honeywell automation systems, supporting continuous operation in process automation, power generation, oil and gas, chemical processing, and other critical industrial applications.
