Product Name:Ground Tap Module
Brand Name:Honeywell
Model Number:51109693-100B
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
51109693-100B |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model Number | 51109693-100B |
| Manufacturer | Honeywell |
| Product Type | Ground Tap Module |
| Description | Ground Tap 2-4 Tap with Terminators |
| Input Channels | 16 Channels |
| Maximum Input Voltage | 36 VDC |
| Input Current | 7 mA @ 24 VDC |
| Input HIGH Level | > 15 VDC |
| Input LOW Level | < 9 VDC (I < 2 mA) |
| Input Delay | Typical 10 ms |
| Power Requirement (5 VDC) | 8 mA |
| Power Requirement (24 VDC Internal) | 110 mA |
| Power Requirement (24 VDC External) | 110 mA |
| Ripple Content | < 0.5 Vp-p (0–360 Hz) |
| Space Requirement | 4 TE, 3 HE (4 HP, 3U) |
| Dimensions | 12 cm × 9.8 cm × 4 cm |
| Weight | 0.22 kg |
| Country of Origin | USA |
The Honeywell 51109693-100B Ground Tap Module is a reliable industrial interface component designed for secure grounding, signal integrity, and dependable field connection management within Honeywell automation and control systems. Engineered for demanding industrial environments, it helps maintain stable signal transmission while supporting safe and efficient system operation.
Designed with compact dimensions and low power consumption, the 51109693-100B supports multiple input channels and offers dependable performance for process monitoring and control applications. Its integrated terminator configuration simplifies installation and enhances wiring organization in complex control cabinets.
Compatible with various Honeywell control architectures, including modules such as 51109693-100B, 51109694-100, and related I/O interface assemblies, this grounding solution contributes to improved system reliability, reduced electrical noise, and long-term operational stability in industrial automation environments.
Power Plants: Used for generator monitoring systems and control signal grounding; supports relay protection and distributed control systems; enhances signal integrity in critical power generation processes.
Substations: Enables reliable signal termination and grounding functions; supports switchgear monitoring and protection systems; improves communication stability within automation networks.
Chemical Plants: Integrates with process control and instrumentation systems; helps minimize electrical noise in sensitive measurement circuits; supports continuous operation in demanding industrial environments.
Steel Mills: Provides dependable grounding in high-temperature production areas; supports automation equipment exposed to strong electromagnetic interference; enhances control system stability for heavy industrial processes.
Machinery Manufacturing Plants: Used in automated production lines and assembly systems; supports PLC-based monitoring and control applications; simplifies cabinet wiring and equipment maintenance.
Oil & Gas Facilities: Assists with field signal management and equipment grounding; supports control and monitoring systems in processing units; improves operational safety and system reliability.
Water & Wastewater Treatment Plants: Supports instrumentation and control panel installations; provides stable signal connections for monitoring equipment; helps ensure uninterrupted plant automation performance.
Q1: What is the Honeywell 51109693-100B used for?
A1: It is a Ground Tap module designed to provide secure grounding, signal termination, and reliable field signal connections in industrial automation systems.
Q2: How many input channels does the 51109693-100B support?
A2: The module supports up to 16 input channels for industrial monitoring and control applications.
Q3: What is the maximum input voltage of the module?
A3: The maximum supported input voltage is 36 VDC.
Q4: Is the 51109693-100B suitable for harsh industrial environments?
A4: Yes, it is designed for reliable operation in demanding environments such as power plants, chemical facilities, and manufacturing sites.
Q5: Does the module include built-in terminators?
A5: Yes, the Honeywell 51109693-100B is supplied with integrated terminators to simplify installation and improve signal management.
| 51403902-100 | Breaker Box Assembly |
| F660A | REDUNDANT FIELDBUS POWER SYSTEM |
| FCAB-05 | FIELDBUS IOTA POWER CABLE 30CM |
| FCAB-08 | POWER CABLE, MTL FIELDBUS IOTA 4M |
| TK-FFSU01 | FIELDBUS RTP, REDUNDANT UNPOWERED COATED |
| SPS5710 | POWER SUPLY |
| 8937-HN | MODULO DE FIBRA OPTICA |
| 65-800764-6-00 | MODULE LAN /RS 232/422/485 |
| 51202951-100 | IMRK MTL4541B |
| 51202954-100 | IMRK MTL4516 |
| 51202957-100 | IMRK MTL4525 |
| 42622212-016 | HART IF MOD |
| MTL4561 | MTL FIRE AND GAS DETECTOR INTERFACE |
