Product Name:Power Control Module Assembly
Brand Name:Honeywell
Model Number:51307038-100
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
51307038-100 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification |
|
Product Model |
51307038-100 |
|
Product Type |
Power Control Module Assembly |
|
Compatible System |
Honeywell Series 8 / Experion LX |
|
Input Voltage Range |
16 ~ 32 VDC |
|
Number of Inputs |
2 |
|
Number of Outputs |
8 |
|
Maximum Load Current |
20 A Max @ 24 VDC |
|
Output Voltage |
24 VDC |
|
Under-Voltage Protection |
Shutdown below 19 V |
|
Over-Voltage Protection |
Shutdown above 28 V |
|
Alarm Function |
DC input abnormal status alarm |
|
Mounting Method |
DIN Rail / Series 8 IOTA |
|
Operating Function |
Power distribution for FIM4 systems |
|
Dimensions |
15x12x7.5cm |
|
Weight |
0.7kg |
51307038-100 is a reliable Power Control Module Assembly designed for Honeywell Series 8 Foundation Fieldbus systems and Experion LX architectures. It delivers stable 24 VDC power distribution for S8-KFB4A1 redundant FIM4 kits and S8-KFB4B1 non-redundant configurations, ensuring continuous communication and dependable fieldbus performance in industrial automation environments.
Built for advanced process control applications, 51307038-100 supports isolated power management for H1 Foundation Fieldbus networks while helping maintain secure and efficient system operation. Its integrated protection mechanisms include under-voltage shutdown, over-voltage shutdown, and alarm signaling for abnormal DC input conditions.
The module is widely used in power generation, petrochemical plants, and manufacturing facilities where stable fieldbus power and high system reliability are essential. With rugged industrial construction and seamless compatibility with Honeywell Series 8 components, 51307038-100 enhances control system availability and operational efficiency.
Power Plants: Used for generator set monitoring, turbine automation systems, and stable Foundation Fieldbus power distribution in critical power generation environments.
Substations: Supports relay protection, switchyard automation, communication interfaces, and reliable DC power management for industrial control cabinets.
Chemical Plants: Provides dependable power supply for process control systems, hazardous-area monitoring, and Foundation Fieldbus network integration.
Steel Mills: Ensures continuous operation of automation equipment under high temperatures, vibration, and strong electromagnetic interference conditions.
Machinery Manufacturing Plants: Applied in automated production lines, robotic workstations, packaging systems, and industrial machine control applications requiring stable control power.
Q1: What is the main function of 51307038-100?
A1: It provides regulated 24 VDC power for Honeywell Series 8 FIM4 fieldbus systems.
Q2: Is 51307038-100 compatible with redundant configurations?
A2: Yes, it supports both redundant and non-redundant FIM4 installations.
Q3: What protection features are included in this module?
A3: The module includes under-voltage shutdown, over-voltage shutdown, and alarm signaling functions.
Q4: Which systems commonly use 51307038-100?
A4: It is widely used in Honeywell Experion LX and Series 8 industrial automation systems.
Q5: Can 51307038-100 be installed on DIN rails?
A5: Yes, the module is designed for DIN rail and Series 8 mounting assemblies.
