Product Name:Digital Input 24VDC
Brand Name:Honeywell
Model Number:8C-TDIL51 51306969-175
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
8C-TDIL51 51306969-175 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification |
|
Model |
8C-TDIL51 51306969-175 |
|
Input Channels |
32 points |
|
Rated Voltage |
24 VDC |
|
Operating Voltage Range |
18–30 VDC |
|
Isolation |
1000 VAC RMS optical isolation |
|
Current Consumption |
~95 mA |
|
Input Impedance |
4.2 KΩ |
|
Response Time |
≤ 5 ms |
|
Mounting Type |
IOTA-based modular mounting |
|
Dimension (W×H×D) |
22x12x5.2cm |
|
Weight |
0.26kg |
The 8C-TDIL51 51306969-175 is a high-reliability 32-channel digital input solution designed for modern distributed control systems. Engineered within the Series 8 architecture, it delivers stable 24VDC signal acquisition for industrial automation environments requiring high-speed response and strong electrical isolation. It supports both non-redundant and redundant IOTA configurations, ensuring flexible deployment in critical process applications.
Built on Honeywell’s advanced Series 8 platform, the module integrates seamlessly with related components such as 8C-PDIL51 and 8C-TDIL61, enabling scalable system expansion. Its optical isolation design improves noise immunity and enhances signal integrity in harsh electrical environments.
With modular installation, fast response performance, and robust diagnostics, the system reduces maintenance effort while improving operational uptime. It is optimized for mission-critical industries including energy, petrochemical, and manufacturing automation systems.
Q1: What is the main function of 8C-TDIL51?
A1: It is used to receive and process 24VDC digital input signals in industrial control systems.
Q2: How many input channels does it support?
A2: It supports up to 32 discrete input channels.
Q3: Does it support redundancy?
A3: Yes, it is compatible with redundant IOTA configurations for higher system reliability.
Q4: What isolation protection is provided?
A4: It provides up to 1000 VAC RMS optical isolation between field and system.
Q5: Where is it commonly used?
A5: It is widely used in power plants, substations, chemical plants, and manufacturing automation.
| Number | Description |
|---|---|
| 8C-TDIL51 | Digital Input 24VDC module, coated, 32-channel, Series 8 system I/O module |
| 8U-TDIL51 | Digital Input 24VDC module, uncoated version for standard environments |
| 8C-TDIL61 | Redundant 24VDC Digital Input IOTA, coated, 12-inch platform |
| 8U-TDIL61 | Redundant 24VDC Digital Input IOTA, uncoated, extended configuration |
| 8C-PDIL51 | Standard 24VDC Digital Input module for Series 8 I/O system |
| 8U-PDIL51 | Uncoated version of 24VDC Digital Input module for general industrial use |
