Honeywell 8C-TDODA1 51307149-175 Digital Output 24VDC Ready For Ship, China Honeywell 8C-TDODA1 51307149-175 Digital Output 24VDC Ready For Ship Manufacturers, Suppliers, Factory

Overview

Brand Name:	Honeywell
Model Number:	8C-TDODA1 51307149-175
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Details
Model	8C-TDODA1 / 51307149-175
Type	Digital Output IOTA Module (24VDC, 32-channel)
Output Type	Current sinking digital output
Voltage	24 VDC
Channels	32 points
Isolation	System-to-field via IOTA design
Temperature Range	0°C to 60°C (operating)
Storage Temp	-40°C to 85°C
Mounting	DIN rail / Series 8 IOTA platform
Dimension	22x12x6.5cm
Weight	0.36kg

Description

The8C-TDODA1 51307149-175Digital Output IOTA module is a high-density 24VDC control interface designed for reliable signal switching in Honeywell Series 8 automation systems. It delivers stable discrete output performance for driving field devices such as solenoid valves, relays, and process actuators in distributed control environments.

Built on the Series 8 architecture, the8C-TDODA1supports 32-channel output configuration with compact integration on a 9-inch non-redundant IOTA. Its modular design enables simplified installation, reduced wiring complexity, and improved maintenance efficiency across industrial control panels.

Engineered for industrial-grade operation, the8C-TDODA1 51307149-175provides robust diagnostics, protected switching circuits, and seamless compatibility with C300-based systems. It is widely used in process automation systems requiring stable digital output control under demanding operational conditions.

Applications

Power plants: generator monitoring and relay control
Substations: switchyard signal acquisition and protection logic
Chemical plants: process automation and safe signal handling
Steel mills: high-temperature industrial control systems
Machinery manufacturing: automated production line control

Features

32-channel high-density digital output design
Modular IOTA-based architecture
Built-in diagnostics for signal integrity
Redundancy-ready system configuration
Compact installation with reduced wiring effort

Functions

ON/OFF switching control for field devices
Solenoid valve and relay actuation
Process logic execution support
Signal distribution in DCS systems

FAQ

Q1: What is the main function of 8C-TDODA1?
A1: It provides 32-channel 24VDC digital output control for industrial automation systems.

Q2: Is 8C-TDODA1 suitable for redundant systems?
A2: Yes, it supports redundant configurations when used with compatible IOTA assemblies.

Q3: What type of devices can it control?
A3: It can control solenoid valves, relays, and other discrete field equipment.

Q4: What voltage does it operate on?
A4: The module operates on a standard 24 VDC output system.

Q5: Can it be used in harsh environments?
A5: Yes, it is designed for industrial environments with temperature and EMI resistance.

Spares

Number	Describe
8C-TAIMA1 / 8U-TAIMA1	TC/RTD IOTA module, coated or uncoated version, designed for thermocouple and RTD signal acquisition, 16-channel support, 9-inch IOTA platform for Series 8 system integration
8C-TAIXA1 / 8U-TAIXA1	Analog input single-ended IOTA module, 16-channel, 6-inch size, supports standard analog signal processing for Series 8 control systems
8C-TAIDA1 / 8U-TAIDA1	Analog input differential IOTA module, 16-channel, 9-inch configuration, optimized for stable multi-signal acquisition in industrial environments
8C-TAIXB1 / 8U-TAIXB1	Redundant single-ended analog input IOTA module, 16-channel, 12-inch design, enhanced reliability for critical process control applications
8C-TAIDB1 / 8U-TAIDB1	Redundant differential analog input IOTA module, 16-channel, 12-inch structure, designed for high-availability industrial automation systems
8C-TAOXA1 / 8U-TAOXA1	Analog output IOTA module, 16-channel, 6-inch format, supports precise 4–20mA output control for process regulation
8C-TAOXB1 / 8U-TAOXB1	Redundant analog output IOTA module, 16-channel, 12-inch configuration, built for high-reliability output control systems
8C-TDILA1 / 8U-TDILA1	Digital input 24VDC IOTA module, 32-channel, 9-inch design, coated or uncoated version for industrial signal acquisition
8C-TDILB1 / 8U-TDILB1	Redundant digital input 24VDC IOTA module, 32-channel, 12-inch structure, high-availability input solution for Series 8 systems
8C-TDODA1 / 8U-TDODA1	Digital output IOTA module, 32-channel, 9-inch format, standard 24VDC output control for industrial automation systems
8C-TDODB1 / 8U-TDODB1	Redundant digital output IOTA module, 32-channel, 12-inch design, high-reliability output module for critical control applications
